If you are replacing an existing card, hold the PCI card at each end, and carefully rock it back

and forth until the connectors pull free from the socket. Pull the expansion card toward the left

side of the chassis straight out of the riser. Be sure not to scrape the card against the other

components.

NOTE:

attached to the expansion card.

Figure 2-20

11.

Store the removed card in anti-static packaging.

12.

If you are not installing a new expansion card, install an expansion slot cover to close the open

slot.

CAUTION:

slot cover for proper cooling of internal components during operation.

ENWW

Before removing an installed expansion card, disconnect any cables that may be

Removing a Standard PCI Expansion Card

After removing an expansion card, you must replace it with a new card or expansion

Removing or Installing an Expansion Card
