20.
Lock any security devices that were disengaged when the computer cover was removed.
21.
Reconfigure the computer, if necessary. Refer to the Computer Setup (F10) Utility Guide on the
Documentation and Diagnostics CD for instructions about using Computer Setup.
Drive Positions
Figure 2-23
1
5.25-inch external drive bay with optical drive installed (some models)
2
Primary 3.5-inch internal hard drive bay
3
Secondary 3.5-inch internal hard drive bay
To verify the type, size, and capacity of the storage devices installed in the computer, run Computer
Setup. Refer to the Computer Setup (F10) Utility Guide on the Documentation and Diagnostics CD for
more information.
ENWW
Drive Positions
Drive Positions
27
