Elation Design LED 12 Brick Technical Specifications page 3

Design LED 12 Brick
DMX TRAITS
6 Channel Mode:
Channel Value Function
Red ( 0 - black, 255 - 100% red )
1 0 - 255
Green ( 0 - black, 255 - 100% green )
2 0 - 255
3 221 - 255 Blue ( 0 - black, 255 - 100% blue )
4 0 - 255 Internal programs
5 0 - 255 Strobe
6 0 - 255 General dimming, program speed control
12 Channel Mode:
Channel Value Function
Red ( 0 - black, 255 - 100% red )
1 0 - 255
Green ( 0 - black, 255 - 100% green )
2 0 - 255
3 221 - 255 Blue ( 0 - black, 255 - 100% blue )
4 0 - 255 Red ( 0 - black, 255 - 100% red )
5 0 - 255 Green ( 0 - black, 255 - 100% green )
6 221 - 255 Blue ( 0 - black, 255 - 100% blue )
Red ( 0 - black, 255 - 100% red )
7 0 - 255
Green ( 0 - black, 255 - 100% green )
8 0 - 255
9 221 - 255 Blue ( 0 - black, 255 - 100% blue )
Red ( 0 - black, 255 - 100% red )
10 0 - 255
Green ( 0 - black, 255 - 100% green )
11 0 - 255
12 221 - 255 Blue ( 0 - black, 255 - 100% blue )
15 Channel Mode:
Channel Value Function
Red ( 0 - black, 255 - 100% red )
1 0 - 255
Green ( 0 - black, 255 - 100% green )
2 0 - 255
3 221 - 255 Blue ( 0 - black, 255 - 100% blue )
4 0 - 255 Red ( 0 - black, 255 - 100% red )
5 0 - 255 Green ( 0 - black, 255 - 100% green )
6 221 - 255 Blue ( 0 - black, 255 - 100% blue )
Red ( 0 - black, 255 - 100% red )
7 0 - 255
Green ( 0 - black, 255 - 100% green )
8 0 - 255
9 221 - 255 Blue ( 0 - black, 255 - 100% blue )
Red ( 0 - black, 255 - 100% red )
10 0 - 255
Green ( 0 - black, 255 - 100% green )
11 0 - 255
12 221 - 255 Blue ( 0 - black, 255 - 100% blue )
13 0 - 255 Internal programs
14 0 - 255 Strobe
15 0 - 255 General dimming, program speed control
