ELED Fresnel 150
Unpacking:
Thank you for purchasing the ELED Fresnel 150 by Ela-
tion Professional
. Every ELED Fresnel 150 has been thoroughly tested
®
and has been shipped in perfect operating condition. Carefully check
the shipping carton for damage that may have occurred during ship-
ping. If the carton appears to be damaged, carefully inspect your fix-
ture for any damage and be sure all accessories necessary to operate
the unit has arrived intact. In the case damage has been found or parts
are missing, please contact our customer support number for further
instructions. Do not return this unit to your dealer without first contact-
ing customer support.
Introduction:
The ELED Fresnel 150 is part of Elation Profession-
als
continuing pursuit for creating high quality affordable intelligent
®
fixtures. The ELED Fresnel 150 is a powerful DMX intelligent LED spot.
The unit can be controlled manually or via DMX controller.
Customer Support:
provide set up help and to answer any question should you encounter
problems during your set up or initial operation. You may also visit us
on the web at www.elationlighting.com for any comments or sugges-
tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacific Standard Time.
Voice:
Fax:
E-mail:
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
Elation customer support.
©
PLEASE recycle the shipping carton when ever possible.
®
