CPU Configuration

The items in this menu show the CPU-related information that the BIOS
automatically detects.
Extreme Tweaker
Configure advanced CPU
Manufacturer:Intel
Brand String:Intel(R) Core(TM)2 Duo CPU E6750 @
Frequency
FSB Speed
Cache L1
Cache L2
Ratio Status:Unlocked (Min:06, Max:08)
Ratio Actual Value: 8
CPUID
Ratio CMOS Setting
C1E Support
Max CPUID Value Limit
Intel(R) Virtualization Tech [Enabled]
CPU TM function:
Execute Disable Bit
Intel(R) SpeedStep(TM) Tech
Intel(R) C-STATE Tech
Ratio CMOS Setting [Auto]
Allows you to adjust the ratio between CPU Core Clock and FSB Frequency.
Enter a ratio using the numeric keypad, and the system will detect possible
values. Use the <+> and <-> keys to select a ratio. The valid value ranges
differently according to your CPU model.
C1E Support [Enabled]
Allows you to enable or disable Enhanced Halt State support.
Configuration options: [Disabled] [Enabled]
Max CPUID Value Limit [Disabled]
Setting this item to [Enabled] allows legacy operating systems to boot even
without support for CPUs with extended CPUID functions.
Configuration options: [Disabled] [Enabled]
Intel(R) Virtualization Tech [Enabled]
The Intel
multiple operating systems separately and simultaneously, enabling one
system to virtually function as several systems.
Configuration options: [Disabled] [Enabled]
CPU TM function [Enabled]
This function enables the overheated CPU to throttle the clock speed to cool
down. Configuration options: [Disabled] [Enabled]
Execute Disable Bit Capability [Enabled]
Allows you to enable or disable the No-Execution Page Protection
Technology. Setting this item to [Disabled] forces the XD feature flag to
always return to zero (0). Configuration options: [Disabled] [Enabled]
3-18
settings
2.66GHz
:2.66GHz
:1332 MHz
:64 KB
:4096 KB
:6FB
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
Virtualization Technology allows a hardware platform to run
®
BIOS SETUP UTILITY
[Auto]
[Enabled]
[Disabled]
[Enabled]
[Enabled]
[Enabled]
[Enabled]
Sets the ratio between
CPU Core Clock and the
FSB Frequency.
NOTE: If an invalid
ratio is set in
CMOS then actual and
setpoint values may
differ.
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Chapter 4: BIOS setup
