DRAM RAS# Precharge [5 DRAM Clocks]
Configuration options: [3 DRAM Clocks] [4 DRAM Clocks]–[18 DRAM Clocks]
DRAM RAS# Activate to Precharge [15 DRAM Clocks]
Configuration options: [3 DRAM Clocks] [4 DRAM Clocks]–[18 DRAM Clocks]
RAS# to RAS# Delay [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
Row Refresh Cycle Time [Auto]
Configuration options: [Auto] [20 DRAM Clocks] [25 DRAM Clocks]
[30 DRAM Clocks] [35 DRAM Clocks] [42 DRAM Clocks]
Write Recovery Time [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
Read to Precharge Time [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
2nd Information : 8-3-5-4-6-4-6 (These values are auto-detected)
READ to WRITE Delay (S/D) [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
WRITE to READ Delay (S) [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
WRITE to READ Delay (D) [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
READ to READ Delay (S) [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
READ to READ Delay (D) [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
WRITE to WRITE Delay (S) [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
WRITE to WRITE Delay (D) [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
3rd Information : 13-5-1-6-6 (These values are auto-detected)
WRITE to PRE Delay [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
READ to PRE Delay [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
PRE to PRE Delay [Auto]
Configuration options: [Auto] [1 DRAM Clocks] [2 DRAM Clocks] [3 DRAM Clocks]
ALL PRE to ACT Delay [Auto]
Configuration options: [Auto] [1 DRAM Clocks]–[15 DRAM Clocks]
3-14
Delay (D) [Auto]
Delay (D) [Auto]
Delay (D) [Auto]
–[18 DRAM Clocks] [18 DRAM Clocks]
–[18 DRAM Clocks] [18 DRAM Clocks]
–[15 DRAM Clocks] [15 DRAM Clocks]
–[15 DRAM Clocks] [15 DRAM Clocks]
–[15 DRAM Clocks] [15 DRAM Clocks]
–[15 DRAM Clocks] [15 DRAM Clocks]
–[15 DRAM Clocks] [15 DRAM Clocks]
–[15 DRAM Clocks] [15 DRAM Clocks]
–[15 DRAM Clocks] [15 DRAM Clocks]
–[15 DRAM Clocks] [15 DRAM Clocks]
–[15 DRAM Clocks] [15 DRAM Clocks]
–[15 DRAM Clocks] [15 DRAM Clocks]
Chapter 4: BIOS setup
