Configuring Super Speed
This mode allows two hard disks to access data simultaneously. The dual channel
design can largely enhance hard disk transfer rate.
• We recommend that you use two new hard disks for this setup.
• This setup erases all original data in the two hard disks. Back up all data in
them before using this setup.
To start Super Speed configuration:
Click Super Speed from the main screen.
1.
If you are in EZ Backup mode,
click Mode Change to return to
the main screen.
Click Apply to start configuration.
2.
3. A warning message appears, reminding you that all original data in the two
hard disks will be erased. Click Ok to continue.
4. The setup is completed.
The Speeding HDD icon on the
5.
Windows notification area turns
®
green to indicate that Super Speed
is set up successfully.
If one hard disk is corrupt, all data in both hard disks will be lost.
ASUS Maximus II Formula 4-35
