3.8.3

BIOS Flashback

This menu allows you to back up or restore BIOS content from BIOS 1 to BIOS2,
and vice versa.
Tools
Now BIOS status
BIOS Boot Selection
BIOS Update
BIOS1 to BIOS2
BIOS2 to BIOS1
v02.58 (C)Copyright 1985-2008, American Megatrends, Inc.
To perform BIOS Flashback:
1. Highlight [BIOS1 to BIOS2] or [BIOS2 to BIOS1] and press <Enter>.
The system enters the soft-off state and the onboard BIOS LED will blink to
2.
indicate that the update is proceeding.
3. When the update is complete, the system will restart automatically.
Refer to 2. BIOS flash setting (6-pin BIOS_FLASHBACK) in 2.6 Jumpers for
further information.
ASUS Maximus II Formula
BIOS SETUP UTILITY
: BIOS1
: BIOS Menu
BIOS1 to BIOS2
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
3-45
