M- 5
Copyboard

Basic Operation

Quick Reference Guide

These operations are required when storing the drawings
on the copyboards's sheet in the memory and when
moving the sheet surface using buttons.
This quick reference guide is written for computers running
Windows Me/2000/XP. For all other windows operating
1
systems please refer to the M-5 Copyboard manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M-5 and is the answer not in the manual?

Questions and answers

Related Manuals for Plus M-5

Summary of Contents for Plus M-5

  • Page 1: Basic Operation

    M- 5 Copyboard Basic Operation Quick Reference Guide These operations are required when storing the drawings on the copyboards’s sheet in the memory and when moving the sheet surface using buttons. This quick reference guide is written for computers running Windows Me/2000/XP.
  • Page 2 Connecting the AC power adapter and turning the power on and off Connect the AC power adapter. Connect the AC power adapter to the copyboard’s DC power jack. Connect the AC power cord to the AC power adapter. Insert plugs securely Plug the AC power cord into a AC power outlet in a wall.
  • Page 3 Saving the Image on the Sheet Images drawn on the sheet can be stored either in the built-in memory or on a CF memory card. This is a black and white copyboard. Images drawn in color are stored in black and white. Saving sheet images in the built-in memory Preparations: Check that the POWER indicator is lit.
  • Page 4 Clearing the built-in Memory Use this procedure to clear all the image files in the built-in memory. Press the CLEAR button and hold it in for more 3 seconds. Once the CLEAR button has been held in for more 3 seconds, the MEMORY indicator blinks slowly and file clearing starts.
  • Page 5 Store the copyboard’s image folder onto the computer. The folder name for the copyboard’s image files is “PVM”. Select the PVM folder, specify the destination folder to copy it at “Edit” → “Copy to folder” in Explorer, then click “OK”. This is just one example of how to copy the folder.
  • Page 6 Using a memory card reader/writer (USB type) Insert the CF memory card into the CF memory card slot on the memory card reader/writer. Connect the memory card reader/writer to the computer’s USB port. Open “My Computer” of the computer. “My Computer” can also be opened by clicking on its icon. From among the removable memory devices shown in “My Computer”, select the drive corresponding to the CF memory card.
