Copyboard with Memory Function
M - 11S/M - 11W
User's Manual
Thank you for your purchase of the PLUS Copyboard.
Please read this User's Manual carefully before use to take full advan-
tage of the functions of this product. After you have finished reading the
manual, please keep it for future reference.
Advertisement
Table of Contents
Related Manuals for Plus M-11
Summary of Contents for Plus M-11
- Page 1 M - 11S/M - 11W User’s Manual Thank you for your purchase of the PLUS Copyboard. Please read this User’s Manual carefully before use to take full advan- tage of the functions of this product. After you have finished reading the...
- Page 2 Trademarks • Microsoft and Windows are registered trademarks or trademarks in the United States and other countries of the Microsoft Corporation. • Adobe and Adobe Acrobat Reader are trademarks of Adobe Systems Incorporated. The trademarks of the various companies and the product trademarks, even when not written down, will be given due respect. Product names and company names appearing in this manual are registered trademarks or trademarks of the respective companies. (1) The contents of this manual may not be reprinted in part or whole without permission. (2) The contents of this manual are subject to change without notice. (3) Great care has been taken in the creation of this manual; however, should any questionable points, errors, or omissions be apparent, please contact us. (4) Notwithstanding Section (3), this company will not be responsible for any claims of loss or profit or other matters deemed to be the result of using this unit. (5) The use of a printer as the peripheral device of the PLUS Copyboard is taken to be a prerequisite; therefore, operation will not be guaranteed when the Copyboard is used with a direct connection to a personal computer. (6) Manuals with incorrect collating or missing pages will be replaced.
-
Page 3: Table Of Contents
Setting the Time ... E-14 Printing ... E-16 Basic Printing Operation ..E-16 Selecting the printing density ... E-17 Making additional copies ... E-17 Cancellation of the print operation in progress ..E-18 Printing in the same ratio as the sheet surface (Model M-11) ... E-18 Moving the sheet surface manually ... E-18 Using USB Memory ... E-19 USB Memory Storage Procedure ..E-19 Saving Image Files to a Personal Computer, and Deleting Image Files... E-21 Printer Operation Guide ... E-23 Printer Set Up . -
Page 4: Features
Features The Copyboard is a business machine, a whiteboard having an added copying function. It is also called an electronic blackboard. This is a very easy-to-use product equipped with motorized sheet feed- ing that enables copying from a desired position as well as manual sheet movement, and an easy-to-clean pen tray among other features. The Copyboard comes in “real” board sizes of 1300 (W) × 920 mm (H) (and 1800 (W) × 920 mm (H) for Model M-11W). Now you can write down and capture a streaming flow of ideas without missing any. Stylish and Functional Design Retaining the design of the existing M-10 Series, the color has been changed to harmonize with the latest office environments. The operation panel and USB ports have been arranged at the right side to combine a clean-cut design and ease of use. The height of the main unit can be adjusted up and down 3 levels from the standard position. Wall mounting is also permitted. Regular Paper Can be Written on and Kept as a Record A press of the “Print” button on the operation panel quickly prints what has been hand written on the sheet surface to regular A4 size paper. -
Page 5: Important Safety Information
Important Safety Information WARNING The unit’s rear panel should never be opened by anyone other than a qualified serviceperson. Contact your store of purchase to request inter- nal inspection, adjustment, repair, and cleaning. CAUTION Continued use of the unit under abnormal conditions (when the unit is emitting smoke, unusual odors or sounds) could lead to fire or electric shocks. -
Page 6: Cautions On Usage
Important Safety Information Reflected Light from the Sheet Surface The sheet surface of the main unit has a white glaze and when a projector or other optical equipment is projected, the reflected light could result in eye fatigue or other symptoms, so please be careful. Also note that the light emitted from laser pointers can be linked to unexpected accidents, so please refrain from using them. Do not use the included CD-ROM in a player designed for audio CDs. -
Page 7: Handling The Cd-Rom
• As a provision against the unlikely event of a problem with or disappearance of the data saved in the USB memory, we recommend that the data be regularly saved to other media. • PLUS Vision will not be responsible for the loss of content stored in the internal memory of this unit (i.e., images that have been read), or in USB memory. USB Cables Use USB shielded cable that has USB-IF logo compliance. Do not use this unit with a connection to a USB hub. The unit... -
Page 8: Package Contents
Package Contents The package contents are as described below. Please check before use. Copyboard, main unit [1] See “Assembly and Setup Manual” for information about the assembly parts of the copyboard. Printer* [1] Please see the instruction manual of the printer for informa- tion about the printer accessories. Stand* [1] *The printer and stand may be sold separately. Copyboard Accessories • Special markers (One each of black, red, blue, and green) Use these markers to draw on the sheet surface. • Special eraser [1] Use this to erase the drawing. • AC power adapter (with power cord) [1] This is the power adapter for supplying power to the copy- board (See Page E-12). • USB cable (type B type A) [1] Use this cable to connect the copyboard with a computer (See Page E-33). -
Page 9: Names Of The Parts
Names of the Parts Front Pen tray approx. 10 mm Effective reading size approx. 10 mm approx. 10 mm Main unit approx. 10 mm Frame cover Sheet Special markers are used on the sheet to draw diagrams and to write. Control panel (See Page E-10) Printer tray The printer* is placed here. Stand* This stand supports the copyboard. Effective Reading Size The area that can be copied is the gray area of the diagram. Note • It might not be possible to print or copy when storing to USB memory or personal computer any portions that are drawn outside of this range. -
Page 10: Rear
Names of the Parts Rear The connector is located on the bottom surface of the main unit. The diagram view is seen from the bottom. Locking and unlocking the casters of the stand* Lock the casters with the stopper after setup. To move the unit, remove the stabilizers and release the caster stopper. Press the bottom of the stopper to lock it. Press the top to release it. Stabilizer Caster * May be sold separately. Unlock Lock E-10 DC input connector Connect this with the DC plug end of the AC power adapter. (See Page E-13.) (Only connect the supplied AC power adapter; nothing else.) Personal computer (PC) dedicated USB port... -
Page 11: Control Panel
Names of the Parts Control Panel When pressing a button, please press the center area (i.e., the round and protruding portion). Pressing the cor- ner will not work. Number of Copies Print Save Reprint Feed/Stop Density Color ON / Standby MEMORY ON/Standby button Switches the power of the copyboard on and off. The ON/Standby button does not synchronize with the main power control of the Copyboard. Pressing the ON/Standby button in combination with another button permits setting of the current time and the print compression. See pages 14 and 19 for details. -
Page 12: Operation Steps
Operation Steps The copyboard uses a CCD image sensor to read the diagrams and text that have been written down with spe- cial (4-color) markers, and accumulates the image data in internal memory. Pressing the Print button prints out the sheet surface image data from the printer, and pressing the Save button stores the image data to USB memory. Preparation • Set up the newly purchased copyboard and connect a printer. See a separate manual titled “Assembly and Setup Manual.” • Connect the supplied AC power adapter. See Page E-13. • Set the time of the newly purchased copyboard. See Page E-14. Draw on the Sheet Surface Please draw with the special markers that have been supplied. To erase, use the supplied special eraser. Please be sure to draw with the special markers. Failure to do so may result in a drawing that... -
Page 13: Ac Power Adapter Connections
AC Power Adapter Connections To use the copyboard, connect the supplied AC power adapter. Connect the DC plug of the AC power adapter to the DC power connector of the copyboard. Connect the AC power cord to the AC power adapter. Plug the AC power cord into a AC power outlet in a wall. -
Page 14: Setting The Time
Setting the Time The clock of the copyboard should be set correctly because the date and time (timestamp) is printed on the printer paper, and it is also recorded in the file information when saving. Number of Copies Print Save Reprint Feed/Stop Density Color ON / Standby MEMORY Preparation: Connect the AC power adapter to the copyboard. See Page E-13. Example: Set the time to 2:16 pm, November 8, 2006 (2006.11.08 14:16). Press the ON/Standby the power. - Page 15 Setting the Time Press the + button or the − button, select 20 (the first 2 digits of the year), and press the Print button to finalize. There will be a change to the “last 2 digits of the year” set- ting mode ( display). Note • The factory default setting is 20. Pressing the Print button in this condition will result in a change to the “last 2 digits of the year” setting mode.
-
Page 16: Printing
Printing This function prints the sheet screen of the copyboard on the printer connected to the copyboard. Number of Copies Print Save Reprint Feed/Stop Density Color ON / Standby MEMORY Basic Printing Operation Preparation: 1. Set A4 or letter size paper in the printer. See Page E-23. 2. Switch on the printer power. See Page E-23. 3. Connect the AC power adapter to the copyboard. See Page E-13. Press the ON/Standby ON / Standby Note • Press the ON/Standby button to switch on the power. The LED of the dis- play window will light. When the drawing is on the rear sheet, press the Feed/Stop button to bring out the desired surface for printing. -
Page 17: Selecting The Printing Density
Printing Press the + button or the − button and select the number of copies. Number of Copies • When the power is switched on, one copy is selected. • A maximum of 20 copies can be set and the number of copies is displayed in the display window. • Each press of the + button increases the number of copies (by one) and each press of the − button decreases the number of copies. Press and hold the button to switch continuously. Press the Print button to print. Print • The reading operation is performed for a one-sheet portion (while the sheet is scrolled) and the printing operation is performed. -
Page 18: Cancellation Of The Print Operation In Progress
(When the Reprint Please press the ON/Standby button of the copyboard. Printing will be inter- rupted in a little while and the paper will be ejected. Printing in the same ratio as the sheet surface (Model M-11) Model M-11W is the wide type copyboard which will compress printing in the horizontal direction resulting in crowded printing of the A4 size sheet; for example, a circle will become an ellipse. To print in the same aspect ratio as a... -
Page 19: Using Usb Memory
ON / Standby MEMORY Notice USB Memory Compatibility • Note that some types of USB memory devices cannot be used. Please see our home page for details. http://www.plus-vision.com USB Memory Storage Procedure Preparation: Connect the AC power adapter to the copyboard. See Page E-12. Press the ON/Standby ON / Standby Note • Press the ON/Standby button to switch on the power. The LED of the... - Page 20 Using USB Memory Press the Color button and select Color or Black & White. Color • When the power is first switched on, Color/Black & White is selected automatically. Press the Save button to store Save • The reading operation is performed for a one-sheet portion (while the sheet is scrolled) and USB memory storage starts after the scrolling completes. The (5 second) flashing “US” display indicates that the USB memory has not been inserted. Please insert the USB memory and then press the Save button. The (5 second) flashing “FL” display indicates that the USB memory is full. The flashing display will stop when the USB memory device is removed. Replace with a USB memory device having sufficient capacity. See “Meaning of Error Messages” on Page E-30 for other error displays. Note • For some USB memories, some time may be required for recognition. • Do not press the Feed/Stop button during the reading operation. Doing so will interrupt the USB memory storage and only the image data up to that point will be stored.
-
Page 21: Saving Image Files To A Personal Computer, And Deleting Image Files
Saving Image Files to a Personal Computer, and Deleting Image Files Examples of operations follow for saving the image files in the USB memory device to the hard disk of the personal computer, and for deleting the folder when the USB memory capacity is full. (There are various methods that can be used for saving and deleting including the use of Explorer.) See the instruction manual of your personal computer or the software that you are using for information about using a personal computer. The folder name of the copyboard inside USB memory is M-11. Image files are stored in this folder. Image file names are stored as PV-xxxxxx.png (a PNG file) and PV-xxxxxx.htm (an HTML file). “xxxxxx” stands for the date and number (e.g., PV- 06110801.png, PV-06110801.htm). Notice To obtain a display and printing that matches the screen size, open the HTML file in a browser and use the browser. - Page 22 “Empty Recycle Bin” from the pull-down menu. All of the data contained in “M-11” will be deleted. Even when the entire folder is deleted, a new M-11 folder will be created automatically when USB memory is used again with the copyboard. Disconnect the USB memory The disconnecting procedure depends on the computer’s oper-...
-
Page 23: Printer Operation Guide
Printer Operation Guide A printer is used to print the content of what has been drawn on the sheet surface. Depending on the printer, the operation may differ and the names of the parts may be different. Please see your printer instruction manual for details. Printer Set Up Please check that the copyboard and the printer have been connected. See Page E-33. Set the paper. Please use A4 or letter size printer paper. See your printer instruction manual for details. 1) Arrange the paper edges so that they are even. 2) Insert paper at the specified position of the paper tray. 3) Press the paper guide gently until it touches the paper. Switch on the power. Press the power switch. The power indicator will light. This completes the preparation of the printer. A press of the Print button on the copyboard operation panel will read the sheet surface portion and start the printing operation. Notice • Depending on the printer, the display indicators may flash from the time the power is switched on until printing preparation is complet- ed. When this happens, refer to the printer owner's manual, check that preparation has been completed, and then start the copyboard printing operation. When finished printing... -
Page 24: Supplied Software Setup Guide
This drive is used to acquire the scanned data into a computer as an image. * This driver may not work on some applications. * This driver conforms to TWAIN standard (ver. 1.9). • Setup Utility This is a utility for customizing the M-11’s environmental settings. • User’s Manual The User’s Manual is stored on the CD-ROM in PDF format. If Acrobat Reader is not installed on the PC, click “Acrobat Reader” on the menu and install it according to the instructions on the screen. • PLUS Image Viewer This utility is used to display the images stored in a personal computer or print it out. • Acrobat Reader This software is used to view PDF files. · Browsing the CD-ROM Explorer running on the personal computer is used to display the contents of the CD-ROM. · Copyrights and usage conditions This opens the copyrights, usage conditions,etc. Note • When installing on Windows 2000, please install the software with “Administrator” authority (i.e., a user having administrator authority). -
Page 25: Installing The Usb Driver
• Use a USB-IF certified shielded USB cable. When the “New hardware wizard” starts, click the “Next” button. When “M-11 USB Device” is detected, select “Search for a suitable driver for my device (recommended)” (Windows 2000), or “Install from a list or specific location (Advanced)” (Windows XP), then click the “Next” button. - Page 26 Supplied Software Setup Guide Specify “D:\M11USB” (D is the designation of the CD-ROM drive) in the text box and click the “Next” button. Once the driver is found, click the “Next” button. Once installation of the USB compatible device’s driver is complete, click the “End” button.
-
Page 27: Acquiring Images Of The Copyboard Directly By The Computer
• When using a TWAIN compatible application, these operations are possible even if only the TWAIN driver is installed. • The installer will start up when clicked. Follow the messages displayed on the screen to install. Once installation is completed, “Restart computer now?” appears. Click “Yes” to restart the computer. This completes the installation. Acquire copyboard images on the computer using the PLUS Image Viewer Preparation and Check 1. Has the installation of the USB driver on the supplied CD-ROM been completed? (Page E-25) 2. Has the connection been made between the copyboard’s PC dedicated USB port and the USB port of the computer? (Page E-25, step 2) 3. Has installation of the aforementioned “TWAIN Driver” and “PLUS Image Viewer” been completed? Starting the “PLUS Image Viewer”... -
Page 28: Using The Setup Utility
This completes the installation. Starting the Setup Utility Preparation and Check 1. Has the installation of the USB driver on the supplied CD-ROM been completed? (Page E-25) 2. Has the connection been made between the copyboard’s PC dedicated USB port and the USB port of the computer? (Page E-25, step 2) 3. Has installation of the aforementioned “Setup Utility” been completed? Once installed, there is no need to install it again. Starting the Setup Utility On the computer, choose “Start” “Programs” “PLUS Copyboard” “M-11 Setup Utility”. The Setup Utility starts up. *For details on using the Setup Utility, see “M-11 Setup Utility Help”. Perform the USB device disconnection procedure at the computer side before disconnecting the USB cable. See “Disconnecting USB Connections with the Main Unit” on Page E-29. E-28... -
Page 29: Disconnecting Usb Connections With The Main Unit
The disconnection operation will differ depending on the operating system (OS) of the computer. See the com- puter instruction manual or on-screen Help for details. Click the [Hardware Removal] icon Click “Stop M-11 USB Device”. Click [OK] when “The ‘PLUS Copyboard M-11 USB Device’ device can now safely removed from the System” is displayed. (When using Windows XP, [OK] does not appear on the message screen. Simply disconnect. ) Note • The USB drive may not be disconnected properly, for example if the computer is in the process of checking the status of peripherals. -
Page 30: Meaning Of Error Messages
• This unit supports the FAT 12/16 and FAT 32 formats. Perform the formatting with the personal computer. • Please see our home page for information about USB memories that can be used with the copyboard. ( http://www.plus-vision.com ) • Please check the operation with a personal computer. • Please perform USB memory storage again. • Do not insert or remove the USB memory card during processing. -
Page 31: Troubleshooting
USB driver When the copyboard and PC are con- nected, the PC does not recognize the copyboard * If the problem persists, please contact your nearby PLUS Vision sales office, dealer, or store. Condition A press of the Print button does not result in printing. The paper feed is abnormal. -
Page 32: Specifications
Specifications BOARD TYPE (Model name) Form Installation method External dimensions (T-shaped legs*¹) Main unit weight T-shaped legs weight BOARD Panel Size Effective reading size Number of Pages Paging Drive method Reading method Reading illumination light source Reading resolution Reading time Memory Type Compatible FAT types... -
Page 33: Appendix
Appendix Connections between copyboard and printer The installation method at the printer side will differ depending on your printer. (1) Connect the copyboard’s printer connector with the printer’s USB connector using the supplied USB cable. (2) Use the power cable supplied with the printer to connect the AC INPUT power connector of the printer with the (100 V AC) wall outlet. This completes the connection of the printer. Now make the power connections of the copyboard. See “AC Power Adapter Connections” on Page E-13. When connections are completed, fasten the cable with the supplied cable clips. DC IN connector AC INPUT power connector * The printer is an option. * Appearance of printer is for illustration purposes. Printer connector USB cable (supplied) USB connector Power cable supplied with the printer E-33 Wall outlet AC power adapter (supplied) -
Page 34: Changing The Height Of The Unit
Appendix Changing the Height of the Unit This is the height adjustment when setting up the copyboard on the optional stand. The stand height can be adjusted to 3 levels in 100 mm units. CAUTION Please have 2 or more persons hold the unit. If the unit is dropped or falls over, this could cause unexpected injury. Please lock the casters by pushing the lower portion of the lock button. (1) Disconnect the power cable and all other connection lines. (2) Take out the printer and remove the printer tray. Please loosen the printer guide fastening screws before removing the printer.
