Ei Electronics RadioLINK Base Smoke & Heat Alarms Ei168 Technical Specifications

MAINS POWERED 230V~
RF Communication
Model Ei168 RF Base
Designed for use with Easi Fit range of alarms
•
• RF wireless interconnect
Unique house coding feature
•
• Visual RF transmission indicator
Advanced suppression and calibration technology
•
• Radio transmitter and receiver in each base
• Easi-fit design construction
Tamper proof rechargeable lithium battery back up
•
• Low power cell warning
RF performance to EN300220-3
•
• EMC performance to EMC 301489-3
5 year guarantee
•

Product Description

The Ei168 RadioLINK Base transmits a radio frequency
(RF) alarm signal when the unit attached to it senses fire.
When it receives an RF signal from another Ei168 Base,
the attached alarm will sound. It therefore eliminates the
need to install long interconnect wires between all the
alarms on different floors in different rooms.
The Ei168 RadioLINK Base is designed for use with the
Easi Fit range of mains powered alarms. The Ei168 itself
is also mains powered and has rechargeable lithium cells
for back-up in the event of mains failure.
The Ei168 base will normally be wired to the nearest
mains circuit in the ceiling (usually the lighting circuit).
The alarm is then slid onto the base rather than to its
mounting plate. As many as twelve units can be
interconnected in this way
The RF range can be extensively improved by either
adjusting the wire antenna or by converting the base into
a "repeater" i.e. re-transmission of the RF signals.
The Ei168 has built in circuitry to aid suppression of
voltage transients and RF interference.
Operation
• In normal standby mode the amber indicator will light
to indicate transmission of an RF signal
In code mode, the amber indicator will flash to
•
indicate the number of other RF alarms that have
been "learned" in the system
The red indicator on the alarm attached to the Ei168
•
Base will flash rapidly to show an alarm condition for
the smoke detector
The amber light will flash every 10 seconds to
•
indicate that the battery back up is depleted
