MMAC-Plus Management Views
Environmental
Module Section
Client Module
Section
Status Bar

General View Information

The following Þelds appear in the general section of each management view. The
other three sections of the window vary with each management view and are
described in the individual view sections.
For this release of MMAC-Plus Remote Management, Þrmware limitations of the
MMAC-PlusÕs on-board System Management Bus components do not allow an
individual IP address to be assigned to the chassis as a whole; therefore, some
system information that would normally be reßected in these Þelds is unavailable
to remote management.
Other information is read from the Þrst module that MMAC-Plus Remote
Management detects in the chassis upon initializing.
Fields in the general information section of each view include:
Name
This Þeld displays the Þrst detected moduleÕs System Description Ñ a read-only
hardware/Þrmware device description (MIB II Ñ> System Ñ> sysDescr).
If no module is detected in the chassis, this displays the name that you assigned to
the conÞgured MMAC-Plus via the Enter chassis name Þeld (see page 2-2).
Net Address
This Þeld is currently unused. It will read 0.0.0.0.
3-2
Figure 3-1. View Overview
General
Information
Section
System Status
Section
View Change Menu
Slot IP Field
An Overview of Management Views
