Getting Started
Each module must be correctly set up in the Chassis Setup window with the correct slot
! number, type, IP address, and community string.
CAUTION
If you do not conÞgure these parameters correctly for a module, and then exit the Chassis
Setup window, the module will not be displayed in the Chassis window. The Chassis
Setup window will reappear automatically to inform you of a conÞguration problem. Any
incorrectly described module will appear highlighted in red, and will have a
its right.
Clicking on
shown in the example below):
Device is actually in slot X indicates that the device IP has been detected in the chassis,
but the device is installed in a different slot than the one which was conÞgured.
IP address or Community Name is invalid indicates that the device IP address given
was not found in the MMAC-Plus chassis (community names are not used at this time).
Device is not a MMACPlus module indicates that the device that you have identiÞed
in the chassis is not an MMAC-Plus architecture device.
Wrong device type indicates that you have selected the wrong type for the conÞgured
device from the Module Type pull-down menu.
These errors will also be reßected in the Chassis Setup window if a chassis that you had
previously modelled has been physically re-conÞgured between management sessions, so
that the modelled chassis is inaccurate.
Reset the Chassis Setup window so that the correct conÞguration of your MMAC-Plus
chassis is modelled.
The Chassis Setup window will disappear, and a new management view will
appear for the MMAC-Plus Chassis. Refer to Chapter 3, MMAC-Plus
Management Views, for more information on managing your MMAC-Plus
chassis.
2-4
will display one of four status messages at the bottom of the window, (as
names, refer to its Local Management User's Guide . Currently,
public is the only community name supported by remote management.
d. Click OK to save configuration changes to the device database, and to
begin modelling the defined MMAC-Plus chassis.
Note that the next time you initialize MMAC-Plus Remote Management,
the name of the configured chassis will appear in the Enter chassis
name drop-down list menu at the introductory screen.
Initiating MMAC-Plus Remote Management
button to
