The 9F106-02 Module Specific Configuration Screen displays the current
configuration of the module's front panel connections in relation to the FNB rings on
the MMAC-Plus backplane, and allows you to change the configuration.
Module Name: 9F106-02
Slot Number: 12
FNB-1
FNB Status: (INSERTED)
Port-A Status: Link
Port-A Type: FPIM-00
FNB-2
FNB Status: (BYPASS)
Port-A Status: Link
Port-A Type: FPIM-00
SAVE
Figure 1. 9F106-02 Module Specific Configuration Screen
MMAC-Plus LOCAL MANAGEMENT
9F106-02 Configuration
Firmware Revision: 00.00.00
BOOTPROM Revision: 00.00.01
EXIT
AutoConnect: (ENABLED)
Port-B Status: No Link
Port-B Type: FPIM-02
AutoConnect: (DISABLED)
Port-B Status: No Link
Port-B Type: FPIM-02
RETURN
Appendix
3
