Edimax i-Watcher i-Watcher Pan/Tilt Internet IP Camera User Manual page 23

8-4-2. Alert IN with Motion detected mail function (Mail Setting)
When motion detection and Alert IN is enabled, the user can setup the mail function to send
the motion-detected images to the preset mail address. The procedures are as follow:
Motion Detect set to "Enable" state.
Setup the "SMTP Mail Server" and
E-Mail address. (Password use or not)
Enter the sender's email address in
"Sender" field and the recipient's email
address in the "Receiver" field.
The user can change the "Subject" field.
If the mail server needs authentication,
check the "Password" check box. Also, enter
the password; otherwise the "Password" field
does not need to be filled in.
Check the "Send mail when motion detected" check box to enable the operation. If the
check box is not checked, the motion detected send mail function will not be enabled.
Confirm by selecting [Save Settings] option to save the settings.
Note:
If all of the items are enabled resulting in a motion event detection, the i-WATCHER
will send the motion-detected images to the preset email address. The maximum
number of images allowed is 6 images per mail.
8-4-5. Motion detected mail
(Alert IN Enabled)
The received mail will be displayed in
a motion Picture form. It can also be
displayed as separated Images with a
selection of the circle button on the
left side of the Image Viewer.
8-4-6. Motion detected message on main window (Alert IN Enabled)
When the motion detection and Alert IN function both enabled, and a motion detected, a
message will be displayed at the bottom.
Motion detection disabled or Motion detection enabled
23
