- Page 1 IR-112E User Manual 10-2013 / v1.0...
- Page 2 COPYRIGHT Copyright Edimax Technology Co., Ltd. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission from Edimax Technology Co., Ltd.
-
Page 3: Table Of Contents
CONTENTS - Chapter I Introduction ....................4 Highlights of your new Network IP Camera ............4 Safety Instructions ....................5 Packaging Contents ..................... 6 Familiar with your new Network IP Camera ............7 Installation of the Network IP Camera ..............8 Chapter II Using Network IP Camera by Web Interface .......... - Page 4 3-7-2 Media ......................... 43 3-7-3 Event Server ....................... 44 3-8 Recording to Micro SD Card ..................48 3-9 SDHC........................49 3-10 Log ......................... 51 3-11 Device Info ......................52 3-12 Maintenance ......................53 3-13 Language........................ 54 Chapter V Troubleshooting ..................55 Notice According to GNU General Public License Version 2 ..........
-
Page 5: Chapter I Introduction
Chapter I Introduction 1.1 Highlights of your new Network IP Camera Congratulates on purchasing this high-resolution 3Mega pixels network IP Camera! This IP Camera provides 3Mega pixels high-resolution video quality, with the advanced megapixel lens, you can view images remotely in more detail than conventional close-circuit cameras. -
Page 6: Safety Instructions
1.2 Safety Instructions Please follow the safety instructions listed below when you’re using this Network IP Camera, or you would harm this camera and/or yourself! Also, the warranty will become void if you disobey these safety instructions. This Network IP Camera is sophisticated electronic device; do not drop it from high places. -
Page 7: Packaging Contents
1.3 Packaging Contents Please check the contents of your new Network IP Camera when you unpack the package. If any item is missing, please contact your dealer of purchase for help. Item No. Description Quantity Network camera Sun shield kit Screw CDROM Quick installation guide... -
Page 8: Familiar With Your New Network Ip Camera
1.4 Familiar with your new Network IP Camera No. Description IR-LED Day/night sensor Lens: Fixed focal length. DC 5Volt/2A input Network, RJ45 connector [Cable ASSIGNMENT] Item Description DC 5Volt/2A input Network, RJ45 connector, two LED index, orange color is power index, green is network index... -
Page 9: Installation Of The Network Ip Camera
1.5 Installation of the Network IP Camera Please follow the instructions below to setup your new IP camera. 1. Connect Ethernet cable to LAN port. 2. Plug DC power adapter to power outlet on the wall. 3. Connect DC power cable to IP Camera’s DC power connector. 4. - Page 10 6. Remove the front cover to find the Micro-SD card slot. 7. Find the screws in the package, use screwdriver to fix the sun shield on the device’s main body. 8. Secure the wall mouting metal bracket on the wall then secure the bullet camera on the bracket.
-
Page 11: Chapter Ii Using Network Ip Camera By Web Interface
Chapter II Using Network IP Camera by Web Interface 2.1 Locate the IP address of Network IP Camera You can use your new Network IP Camera by its web user interface via web browser. Currently the viewing system requirement for Network IP camera OS: Microsoft Windows XP / Vista / Win7 ■... - Page 12 Note: The contents of the CD-ROM can also be downloaded from the Edimax website: http://www.edimax.com/en/index.php 2. After the installation is complete, double-click the “EdiView_Finder” icon to execute the application. 3. Press ‘Discover’ button to search for all IP Cameras on your local network (make sure all IP Cameras are powered on and connect to local network first).
-
Page 13: Connect To Ip Camera's Web User Interface And Install Activex Plugin
2.2 Connect to IP Camera’s Web User Interface and Install ActiveX Plugin When you know the IP address of IP Camera, you can connect to it by Internet Explorer web browser by entering its IP address in address bar. The use login screen will appear when you get connected: IP Camera’s administrator username and password are ‘admin’... - Page 14 For IE 9: Click ‘Install’ button located at the bottom of IE to install ActiveX plugin. If you’re prompted that: ‘Windows Firewall has blocked some features of this program’ Click ‘Allow access’, or IP Camera will not be able to function properly.
- Page 15 When you’re installing Internet Explorer plugin, you may also be prompted that if you want to allow changes to be made to your computer: Click ‘Yes’ to allow changes. After ActiveX plugin is installed, you should be able to see the video stream from camera.
-
Page 16: Viewing Live Video
2.3 Viewing Live Video After ActiveX control is installed, you can view IP camera’s video by web browser. Just connect to IP camera by web browser and login, then you can see live video from IP camera: There are various controls on web page, here are descriptions of every control item: Item Description... - Page 17 ‘Connect’ button Start live video view. ‘Disconnect’ button Stop live video view. ‘Snapshot’ button Take a snapshot or camera video and save image file on your computer. When you click this button, a new window will appear: Click ‘Save’ button when you see the image you wish to save, and you’ll be prompted to indicate the...
-
Page 18: Client Settings
2.4 Client Settings In ‘Client Settings’ menu, you configure basic IP camera settings like data transfer protocol and data storage folder. To access ‘Client Settings’ menu, click ‘Client Settings’ button on the left. The following screen will appear:... - Page 19 Here are the descriptions of every setup item: Item Description RTSP/RTP over TCP Select this option to use RTSP (Real-Time Streaming Protocol) to transfer video data over TCP. *Refer to the application note ‘RTSP/RTP over TCP/UDP’ for details. RTSP/RTP over UDP Select this option to use RTSP (Real-Time Streaming Protocol) to transfer video data over UDP.
-
Page 20: Chapter Iii Advanced Configuration
Chapter III Advanced Configuration If you wish to configure IP camera’s settings, you can access IP camera’s ‘Configuration’ menu, which provides various kinds of system setting. To access configuration menu, click ‘Configuration’ button on the left. The ‘Configuration’ submenu will appear, please pick a setup item you wish to configure. -
Page 21: System
3-1 System In this menu, you can configure basic IP camera settings like hostname and time. Here are the descriptions of every setup item: Item Description Host Name Input the IP camera’s hostname here, it can be any meaningful words or characters that will help you to identify this IP camera. - Page 22 Timezone Select the time zone of residence from dropdown menu to keep correct date and time. Daylight Saving If the area you live uses daylight saving, check this box; otherwise do not check this box to keep time correct. Keep the current Select this option and date / time setting will not be date and time changed when you click ‘Apply’...
-
Page 23: Security
3-2 Security In this menu, you can configure IP camera’s login account. There are three kinds of account: - Administrator (Can view IP camera’s video and make changes of camera setting) - User (Can view IP camera’s video and see LOG, and change Client Setting and language) - Guest (Can view IP camera’s video , and change language ) There can be multiple users, but only one administrator is allowed, and... - Page 24 Here are the descriptions of every setup item: Item Description Password / Retype Here lists all users existed in IP camera. If you want to Password remove one user, click it in the list, and then click ‘Remove’ (Administrator) button. If no user is existed, ‘New Account’...
-
Page 25: Network
3-3 Network In this menu, you can configure IP camera’s network setting. 3-3-1 ‘General’ setup page Setup IP address for this IP camera. This IP camera supports both IPv4 and IPv6 IP address. Here are the descriptions of every setup item: Item Description Select this option to assign an IP address to LAN port (or obtain... - Page 26 manually. If you don’t have a DHCP server on your local area network, you must use this option to specify an IP address. IP Address(IPv4): Input IPv4 IP address* IP Address(IPv6): Input IPv6 IP address* Prefix Length: Input IPv6 IP address’ prefix length (0-128) Subnet Mask: Input subnet mask Gateway: Input gateway address Primary DNS: Input DNS server’s IP address...
-
Page 27: Advanced' Setup Page
‘http://192.168.2.3:82’ in web browser’s address bar to access IP camera’s web configuration interface. RTSP Port Input RTSP port number. When this port number changes, you must change corresponding settings in external network devices (NVR or CMS software) so they can receive this IP camera’s video. RTP Data Input RTP data port number here. - Page 28 Item Description Multicast Enable video multicast: Multicast Group Address: Input multicast group address here, must be an address between 232.0.0.0 to 232.255.255.255. Multicast video port: Input port number for video multicast here. Multicast RCTP video port: Input port number for RCTP video here.
-
Page 29: Ip Filter
you. You must register a dynamic IP service first. Currently this IP camera supports Dyndns, TZO and No-IP dynamic IP service. Provider: Select dynamic IP service provider. Host Name: Input the host name you obtained from dynamic IP service provider. User name: Input user name used to login dynamic IP service provider. - Page 31 Here are the descriptions of every setup item: Item Description Enable Filter Check this box to enable IP address filter, uncheck this Box to disable this function. Accepted IP list Here lists all IP address that can build connections to this IP camera.
-
Page 32: Video
3-5 Video You can adjust the image of the IP camera in this menu. There are 3 sub-menus in this menu: Image Setting, Video Setting, and Overlay, which can be accessed by tabs on the top:... -
Page 33: Image Setting
3-5-1 Image Setting You can adjust the image parameters in this page. Here are the descriptions of every setup item: Item Description Brightness / Control the image parameters. Click ‘ - ‘ to decrease value, or click Contrast / ‘ + ‘ to increase value. You can also input the value in the field Saturation / directly. - Page 34 horizontally, this will help to correct the orientation of image when IP camera is hanged bottom-up by camera holder. You can click both ‘Vertical’ and ‘Horizontal’ box at the same time. Exposure he default setting is Auto. Camera is able to adjust Exposure Mode related settings automatically.
-
Page 35: Video Setting
different than what you see through your eye), and most of IR lights are coming from sunlight. You can select the behavior or IR-cut filter: - Auto: IR filter will act automatically. If you don’t know if you should use IR filter, select this option. - Always ON(B/W): IR filter is always on. - Page 36 Here are the descriptions of every setup item: Item Description H.264 Select the compression of main stream: H.264. Video Select video resolution. Resolution - H.264: 1920x1080 (1080p) / 1280x960 (960p) / 1280x720 (720p) 720x480 (D1) / 640x480 (VGA) / 320x240 (QVGA) - MPEG4: 1920x1080 (1080p) / 1280x960 (960p) / 1280x720 (720p) 720x480 (D1)
- Page 37 consumes more network bandwidth. When you finish with above settings, click ‘Apply’ button to save changes. Note: MJPEG options are only available for portable devices like cell phone. The ‘Mobile View’ is used to enable cell phone monitoring function. Please download APP from iPhone and Android APP store.
-
Page 38: Overlay Setting
3-5-3 Overlay Setting You can adjust the video overlay parameters in this page. Here are the descriptions of every setup item: Item Description Enable Time Check this box to enable overlaying time stamp on video. Stamp Remove the Check this box to remove time stamp’s background color. You background color may find this will help the readability of time stamp text in of the text... -
Page 39: Motion
background color may find this will help the readability of text in some cases. of the text (Text) Enable Image Check this box to overlay a specific image on video, so you can Overlay show certain text / picture on the video and help people to identify this IP camera. - Page 40 Here are the descriptions of every setup item: Item Description Enable Motion Check this box to enable motion detection. Detection Enable Check this box to enable this motion detection window. You can (Window 1 to select window 1 to 3 to enable up to 3 motion detection Window 3) windows.
-
Page 41: Event
change. Percentage Select the percentage of pixel change that will trigger motion detection alert. Select a lower percentage so you can detect tiny changes in motion detection area. Sensitivity Select the sensitivity level that will trigger motion detection alert. Select a higher sensitivity so you can detect tiny changes in motion detection area. -
Page 42: Settings
3. Event Server: Define the details of remote server. Please refer to following sections for detailed instructions. 3-7-1 Settings This page lists all existing events. You can click ‘Modify’ button to edit an existing event, or ‘Remove’ to delete an existing event. To create a new even, just click “New”... - Page 43 To add a new event, click ‘New’ button and the descriptions of every setup item is listed below: Item Description Enable Setting Check this box to enable this event. If you just want to disable this event temporarily, you can uncheck this box to keep this event and disabling while not deleting it.
-
Page 44: Media
3-7-2 Media You can define what kind of media file should be saved on designated media. Here are the descriptions of every setup item: Item Description One Snapshot Save a picture file when event is triggered. Maximum Save a H.264 video clip. You can also select the recording Video File Size length before and / or after the time when event is triggered in ‘Pre Event’... -
Page 45: Event Server
3-7-3 Event Server You can define the details of remote media server: FTP (File), SMTP (Email), and Samba (File). A Samba server can be any computer running windows operating system with network neighbor function enabled. Many stand-alone network file server also support samba server function. Enable FTP server then it will show the related items of FTP server setting. - Page 46 Here are the descriptions of every setup item: Item Description Enable FTP Check this box to enable FTP server upload. Server - FTP Server: Input FTP server’s IP address or hostname. - Port: Input FTP server’s port number. In most cases it should be default value ‘21’.
- Page 47 Item Description SMTP Server Check this box to enable Email send. - SMTP Server: Input SMTP server’s IP address or hostname. - Port: Input SMTP server’s port number. In most cases it should be default value ‘25’. - Sender Email Address: Input the sender’s email address that will appear in the Email send by IP camera.
- Page 48 Enable SMTP Server then UI shows the items as below. Item Description Samba Server Check this box to enable Samba server file upload. - Samba Server Address: Input Samba server’s IP address or hostname. - Path: Input the path where you want to save file on Samba server, like ‘upload/record’.
-
Page 49: Recording To Micro Sd Card
3-8 Recording to Micro SD Card When a Micro SD card is inserted into IP camera, you can save video files on it. Note: 1. Be sure that the Micro SD Card format should be FAT32. The NTFS format cannot be supported by this camera. 2. -
Page 50: Sdhc
3-9 SDHC The IP camera module has an optional Micro-SD card slot PCBA board. The standard module does not include this board. The UI shows the capacity is 0 MB when the module without Micro-SD card slot and memory card. If you need the function please check the option when you place the order of the IP camera module. - Page 51 page. Set the time range then click “Search” then shows the records like below.
-
Page 52: Log
3-10 Log You can check the usage log of IP camera here. In this page, you can click: 1. First page / Final page: Jump to first / final page of log. 2. Previous / Next: Jump to previous or next page of log. 3. -
Page 53: Device Info
3-11 Device Info You can check the information and network settings of this IP camera. The information are very useful when you need to repair or fix the problem of this IP camera. An example of device info page looks like this:... -
Page 54: Maintenance
3-12 Maintenance You can do some maintenance job about this IP camera here. Here are the descriptions of every setup item: Item Description Reboot Click this button to reboot the IP camera. This function is useful when you find IP camera is not working properly. Reset Clear all settings of IP camera and reset to factory default setting. -
Page 55: Language
3-13 Language You can change the display language of web interface. Click ‘Language’ button and select one language. More languages may available in latest firmware file. -
Page 56: Chapter V Troubleshooting
Chapter V Troubleshooting Please don’t panic when you found this IP Camera is not working properly. Before you send this IP Camera back to us, you can do some simple checks to save your time: Problem Possible solution(s) description Can’t 1) Please check the IP address of IP Camera again. - Page 57 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 58 EU Countries Intended for Use The ETSI version of this device is intended for home and office use in Austria, Belgium, Bulgaria, Cyprus, Czech, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Turkey, and United Kingdom.
- Page 59 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC. French: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 2004/108/EC. Czechian: Toto zařízení je v souladu se základními požadavky a ostatními příslušnými ustanovení...
- Page 60 WEEE Directive & Product Disposal At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment, or returned to the supplier for disposal.
-
Page 61: Declaration Of Conformity
Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European EMC directive (2004/108/EC). Equipment: 2M IP CAMERA BULLET Model No.: IR-112E Report No.: T130711D02-E The following European standards for essential requirements have been followed: EN 55022: 2010 (Class A) CISPR 22: 2008 (Ed 6.0) -
Page 62: Notice According To Gnu General Public License Version 2
Notice According to GNU General Public License Version 2 This product includes software that is subject to the GNU General Public License version 2. The program is free software and distributed without any warranty of the author. We offer, valid for at least three years, to give you, for a charge no more than the costs of physically performing source distribution, a complete machine-readable copy of the corresponding source code. - Page 63 0. This License applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of this General Public License. The ‘“Program’“, below, refers to any such program or work, and a ‘“work based on the Program’“ means either the Program or any derivative work under copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or with modifications and/or translated into another language.
- Page 64 machine-readable copy of the corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or, Accompany it with the information you received as to the offer to distribute corresponding source code.
- Page 65 permitted only in or among countries not thus excluded. In such case, this License incorporates the limitation as if written in the body of this License. 9. The Free Software Foundation may publish revised and/or new versions of the General Public License from time to time.
