Summary of Contents for Edimax IC-7010PT
- Page 2 ErP Announcement Product: Internet Camera (IP Camera) Purpose: 24 hour surveillance and transfer of footage for safety and health reasons as intented use. Detailed description: Health purposes: Users can pass through the Internet (from anywhere) to control the product (IP Camera). It's intended to watch and listen to people who need to be cared for at home and automatically sends e-mails and phone alerts to warn observers and ask for their attention.
- Page 3 Copyright by Edimax Technology Co, LTD. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this Company.
- Page 4 "Download" page.
-
Page 5: Product Information
1. Product Information Congratulations on buying this Edimax IP Camera! You've chosen well. The Edimax IC-7010 series features built-in IR (infra red) LED and motorized Pan/Tilt with viewing angle 355 degree horizontally and 120 degree vertically which makes the cameras suitable for almost all security and surveillance applications. - Page 6 available space OS: Windows 2000/XP/Vista/7...
-
Page 7: Hardware Installation
4. Hardware Installation Please follow the following instructions to set the camera up: Connect the Ethernet cable to your local area network, and connect the other end to the LAN jack of this IP camera. Plug the power adapter to wall socket and connect the power connector to the power jack located at the back of the IP camera. - Page 8 Connect the antennas to the antenna base (for IC-7010PTn only) located at the back of the IP camera. Place the IP camera at a secure place, and point the camera to the place you wish to monitor. If you wish to hang the camera on the ceiling or wall, please use the tripod connector (located at the bottom of the IP camera as shown on the below) to secure the camera.
-
Page 9: Familiar With Key Components
5. Familiar with Key Components Front View Focus Ring IR LED Microphone Wired & Wireless: Power LED Audio LED LAN LED WLAN LED Power LED Audio LED ACT LED LAN LED POE model: Item Description Power When the camera is powered on and ready for access, this LED will light up. - Page 10 (IC-7010PoE only) Wireless When the IP Camera is linked to a wireless network, this LED will light up. The LED will flash (IC-7010PT & while video is transmitted or received through a IC-7010PTn wireless network. only) You can change the aim and focus of the camera...
- Page 11 Back View IC-7010PT: USB Port Audio Connector Power Connector Ethernet Port SD Card Slot...
- Page 12 IC-7010PTn: Ethernet Port Antenna Base Audio Connector Power Connector WPS Button SD Card Slot...
- Page 13 IC-7010PoE: Power Connector Ethernet Port SD Card Slot Audio Connector...
- Page 14 Press the WPS button (click) on the IP Cam and (IC-7010PTn click on the Access Point that you want to only) wirelessly connect it to. Note: The USB port only works with Edimax USB WiFi adapters. Note: Edimax EW-7711HPn, EW-7711UAn, EW-7711USN, EW-7711UMn & EW-7711UTn...
- Page 15 Side View Reset Button Item Description Press the button with pen nib and hold for 5 Reset Button seconds to reset the camera settings to factory default value.
- Page 16 Bottom View Tripod Connector Item Description Tripod Connects to tripod to secure the camera when Connector the camera is not put on a horizontal surface.
-
Page 17: Software Installation
Below we tell you how to get it started up. The following example is for Windows Vista. The procedure is similar for Windows 2000/XP/7. Insert the Edimax CD into your CD-ROM drive. It should start up automatically. If it doesn't, click on “Autorun.exe” in the “Autorun” folder on the CD. - Page 18 The 'Install Wizard' should take you here. Click on „Next‟ to continue your installation. Click on 'Next' to move to the next step. If you wish to install the program to an alternate location, click on „Browse‟ and select a location.
- Page 19 Click „Next‟ to move on to the next step or make your selections here.
- Page 20 Click on „Install‟ to install the program.
- Page 21 If you have Windows Defender or other 3rd party firewall software, you may see the following or a similar message, Please click „Unblock‟ to allow your Edimax IP camera Utility to pass through the firewall. Not doing so may cause the IP...
- Page 22 A new folder named „Internet Camera‟ under „All Programs‟ will be created. Click on 'IP Cam Admin Utility' to connect to the IP camera and use the camera's functions directly.
- Page 23 10. After installation, the system will automatically run the „Administrator Utility‟. On the first page, the cameras found in your network will be listed. Select the one you wish to configure and click on the „Configure Camera‟ icon.
- Page 24 11. You will be prompted to insert your user name and password. The default user name is „admin‟ (unchangeable), and the default password is „1234‟ (changeable). Click „OK‟ to continue. 12. The program will automatically detect the IP address status of your network and suggest a free IP address for the IP Camera using DHCP.
-
Page 25: Web Management Interface
6. WEB Management Interface You can use your WEB browser (Internet Explorer 5.5 or above) to connect to the IP camera. Type the IP address (see 5.12) in the address bar of your web browser. Bookmark the address for ease of future use. - Page 26 IP camera. You should now be able to see the images and hear the sounds captured by the Edimax IP camera. For advanced functions, please refer to instructions in the user manual (also on CD-ROM).
-
Page 27: R&Tte Compliance Statement
R&TTE Compliance Statement This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE) The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000.
