8-3-2. Motion detected mail function (Mail Setting)
When motion detection is enabled, the user can setup the mail function to send the
motion-detected images to the preset mail address. The procedures are as follow:
Motion Detect set to "Enable" state.
Setup the "SMTP Mail Server" and E-Mail
address. (Password use or not)
Enter the sender's email address in "Sender"
field and the recipient's email address in the
"Receiver" field.
The user can change the "Subject" field.
If the mail server needs authentication, check the
"Password" check box. Also, enter the password;
otherwise the "Password" field does not need to
be filled in.
Check the "Send mail when motion detected" check box to enable the operation. If the
check box is not checked, the motion detected send mail function will not be enabled.
Confirm by selecting [Save Settings] option to save the settings.
Note:
If all of the items are enabled resulting in a motion event detection, the i-WATCHER
will send the motion-detected images to the preset email address. The maximum
number of images allowed is 6 images per mail.

8-3-3. Motion detected mail

The received mail will be displayed in a motion
Picture form. It can also be displayed as
separated images with a selection of the circle
button on the left side of
the Image Viewer.

8-3-4. Motion detected message on the main window.

When the motion detection function is enabled, and a motion detected, a message will be
displayed at the bottom.
Motion detection disabled or Motion detection enabled
