Operation
Navigation Overview
During navigation, the screen shows route information and trip data (left screens), but when
you tap the map, additional switches and controls appear for a few seconds (right screenshot).
Most parts of the screen behave as switches.
Symbol
1 Main information. Ex) Next route event.
2 Second upcoming route event
3 Trip information screen
4 GPS position quality
5 Next street
Top row
6 Current street and house numbers on left
and right
Bottom row
7 Map view modes
8 Menu
9 Detour
10 Position menu (appears when navigating a
route)
11 Cursor menu (appears when there is no
GPS position or the Cursor is not at the
current GPS position)
12 Opens/closes the map control switches
(touch this switch to display/hide the
following map control switches).
13 Rotate left, rotate right
Tilt up, tilt down
Zoom in, zoom out
80
80
20
Name Action
Opens the Route Information screen.
Opens the Itinerary.
Opens the Trip information screen.
Opens the Quick menu
n/a
n/a
Switches between 2D, 3D and North up
mode.
Opens the Navigation menu.
Opens the Detour screen. There are two
ways to modify your route.
● The list of saved Search Criteria
● A switch to avoid parts of the route
Opens the Position menu.
Opens the Cursor menu
● Zoom in/out
● Rotate left/right (3D map only)
● Tilt up/down (3D map only)
● Zoom preset switches (2D map only)
● Tilt and zoom preset switches (3D map
only)
● Return to GPS position switch
● Smart Zoom
Rotates the 3D map left or right
Tilts the 3D map
Scales the map
