Icon Information
If the icon is a static
picture, route
calculation is needed.
This icon indicates that
route calculation is in
progress.
Next route event
(Next action)
The following area appears next to the above described rounded area. When you touch this
area, the result depends on what information is currently shown.
Icon Information
There is no valid GPS
position.
Traffic restriction
Second route event
(maneuver after next
maneuver)
Approaching a Road
Safety Camera
Stops the running
simulation
Recalculating route
69
Details
GPS position and an active
route are available, but
automatic off-route recalculation
is switched off, and you deviated
from the route.
Navigation is calculating or
recalculating the route.
GPS position and an active
route are available, and you are
navigating the recommended
route. This area gives you
information about the type and
distance of the next route event.
Details
If there is no valid GPS position,
this symbol appears here.
When GPS position is available
but there is no route to be
navigated, any traffic restrictions
at upcoming intersections are
shown here.
When GPS position and an
active route are both available,
this field shows the route event
that follows the next route event
shown in the above described
area.
This icon appears when you are
approaching a Road Safety
Camera, and the warning for
cameras is enabled in Settings.
This icon is displayed during fly
overs, route simulation and
Track Log playback.
During route recalculation, this
field shows the recalculation
progress between 0% and
100%.
Action
Touch this area to make
Navigation recalculate the
recommended route.
Nothing happens if you
touch this area of the
screen.
Touch this area to open the
Route information screen.
Action
Touch this area to open the
GPS Data screen to check
the signal status or the
connection settings.
Nothing happens if you
touch this area of the
screen.
Touch this area to open the
Itinerary screen with the turn
by turn guidance
instructions.
Touch this area to suppress
the audible camera warning.
Touch this area to stop the
simulation.
Nothing happens if you
touch this area of the
screen.
