ESN (Eclipse Security
Network) Setting
This receiver has a built-in ESN (ECLIPSE
Security Network function. ESN is a security
system which renders the navigation and
audio functions inoperable when the battery
terminal is disconnected and reconnected.
You can make the security indicator flash
when the security system is in operation.
INDICATOR
To operate ESN, register a music CD as a
key CD in this receiver.
CHECK
● The flashing of the security indicator works
to discourage theft.
● A DVD or MP3/WMA disc cannot be
registered as the key CD.
● When setting the security on this receiver,
register a music CD. Be sure to store the
registered music CD somewhere safe.
● When setting the security, the audio is
turned OFF.
35

■ ESN setting screen display

1
Press .
2
Touch .
Info
3
Touch .
ESN
● The ESN setting screen is displayed.
