- Page 1 Powerware BladeUPS Bar ® ® Installation Guide...
-
Page 2: Special Symbols
Special Symbols The following are examples of symbols used on the UPS or accessories to alert you to important information: RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of electric shock symbol. CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manual for additional information, such as important operating and maintenance instructions. -
Page 3: Table Of Contents
Table of Contents Introduction ............Safety Warnings . - Page 4 TABLE OF CONTENTS ® ® EATON Powerware BladeUPS Bar Installation Guide 164201723 Rev P01...
-
Page 5: Introduction
Chapter 1 Introduction Up to six of Eaton’s Powerware systems (UPSs) can be installed in an industry standard rack outfitted with a BladeUPS Bar 60 for interconnecting the cabinets’ wiring. Figure 1 shows an installed BladeUPS Bar 60. The wireway fits into the bottom 6U of standard rack space. -
Page 6: Safety Warnings
INTRODUCTION Safety Warnings This manual contains important instructions that you should follow during installation and maintenance of the BladeUPS Bar 60. Please read all instructions before operating the equipment and save this manual for future reference. Denne manual indeholder vigtige instruktioner, som skal følges under installation og betjening af BladeUPS Bar 60-enheden. -
Page 7: Importanti Istruzioni Di Sicurezza
INTRODUCTION WICHTIGE SICHERHEITSANWEISUNGEN AUFBEWAREN Dieses Handbuch enthält wichtige Hinweise, welche Sie bei der Installation und Wartung des BladeUPS Bar 60 beachten sollten. Bitte lesen Sie alle Anweisungen des Handbuches bevor sie mit dem Gerät arbeiten. Bewaren Sie das Handbuch zum Nachlesen auf. IMPORTANTI ISTRUZIONI DI SICUREZZA CONSERVARE QUESTE ISTRUZIONI Il presente manuale contiene importanti istruzioni da seguire durante l’installazione e il... -
Page 8: Instrucciones De Seguridad Importantes
INTRODUCTION INSTRUCCIONES DE SEGURIDAD IMPORTANTES Este manual contiene instrucciones importantes que debe seguir durante la instalación y el funcionamiento del BladeUPS Bar 60. Por favor, lea todas las instrucciones antes de poner en funcionamiento el equipo y guarde este manual para referencia en el futuro. Den här anvisningen innehåller viktiga instruktioner som du ska följa under installation och användning av BladeUPS Bar 60. -
Page 9: Installation
Chapter 2 Installation This section explains: Equipment inspection BladeUPS Bar 60 setup and installation Inspecting the Equipment If any equipment has been damaged during shipment, keep the shipping cartons and packing materials for the carrier or place of purchase and file a claim for shipping damage. -
Page 10: Checking The Package Contents
INSTALLATION Checking the Package Contents Verify that the following items are included: BladeUPS Bar 60 A six-socket bar with (1) attached terminal block assembly, (1) attached base bracket, and (3) attached mounting brackets Wireway main housing with (2) attached side brackets, (1) attached terminal block housing, and (1) attached wireway access cover Front cover mounting panel (2) front covers... -
Page 11: Installation
Installation To install the BladeUPS Bar 60: Remove the access cover and terminal block housing from the wireway housing (see Figure 2). Retain the wireway terminal block housing, wireway access cover, and screws. Leave the two side brackets installed on the wireway housing (see side bracket locations in Figure 3). - Page 12 INSTALLATION Install an M6 hex nut onto each of the three wireway studs to secure the wireway to the rear of the rack. Install the first stud in the fourth hole location from the bottom. Do not tighten the nuts. Figure 4 shows the nuts installed.
- Page 13 Place the ferrite assembly on the floor of the wireway and secure with the supplied tie wrap. Loop the tie wrap through both attachment sites on the wireway floor and through the ferrite assembly. See Figure 4. 10. Note the orientation of the base bracket installed on the bar for later re-installation (see Figure 5).
- Page 14 INSTALLATION NOTE Verify that the bar is secure as shown in Figure 4. The sheetmetal at the base of the bar should be below the tab on the wireway floor. 12. Secure the bar to the wireway with three M6 the bolts from the front of the rack.
- Page 15 14. Secure the base bracket to the rack with three M6 Install the bolts from the rear of the rack. Use a large screwdriver or crowbar to lift the bar in place to align the holes in the base bracket with the holes in the rack. Install the lowest bolt in position 2, then use positions 9 and 15.
- Page 16 INSTALLATION 16. Install two M4 floor, securing the base of the bar to the wireway. See Figure 7. Torque the screws to 1.7 ± 0.2 Nm (15 ± 2 lb in). Rear of Rack Figure 7. Wireway Tab Attachment ® ®...
- Page 17 × 17. Using two M6 12 hex bolts, secure the left side of the wireway terminal block housing to the rack. See Figure 8. Torque the bolts to 5.1 ± 0.8 Nm (45 ± 7 lb in). × 18. Using nine M4 8 pan-head screws, secure the wireway terminal block housing to the wireway and to the bar.
- Page 18 INSTALLATION 19. Using five M4 cover. See Figure 9. Torque the screws to 1.7 ± 0.2 Nm (15 ± 2 lb in). 20. Verify the six information labels are attached to the wireway as shown in Figure 10. ® ® EATON Powerware BladeUPS ×...
- Page 19 × 21. Using four M5 16 hex bolts and four M5 cage nuts, secure the front cover mounting panel to the front of the rack. Verify that the bent edge of the panel is at the top. See Figure 11. Install the lower bolts and cage nuts into the second holes from the bottom of the rack frame.
- Page 20 INSTALLATION 22. Snap the two front covers into place, as shown in Figure 12. Figure 12. Front Cover Installation ® ® EATON Powerware BladeUPS Bar Installation Guide 164201723 Rev P01 Front Covers (2 pieces)
-
Page 21: Specifications
Chapter 3 Specifications This section provides the following specifications: Table 1. BladeUPS Bar 60 Dimensions (WxDxH) Depth of Wireway Weight UPS Connections Rack Placement EATON Powerware × × × 14.0 11.3 183.8 cm (5.5” 90.1 cm (35.5”), excluding front covers Bar: 19 kg (42 lb) Wireway enclosure: 20 kg (45 lb) Total Weight: 39 kg (87 lb) - Page 22 SPECIFICATIONS ® ® EATON Powerware BladeUPS Bar Installation Guide 164201723 Rev P01...
-
Page 23: Service And Support
Chapter 4 Service and Support If you have any questions or problems with the BladeUPS Bar, call your Local Distributor or the Help Desk at one of the following telephone numbers and ask for a UPS technical representative. United States: Canada: All other countries: Please have the following information ready when you call the Help... - Page 24 SERVICE AND SUPPORT ® ® EATON Powerware BladeUPS Bar Installation Guide 164201723 Rev P01...
- Page 28 *164201723P01* 164201723 P01...
