Get Started with

Simulation

AutodeskInventor

Simulation provides tools to simulate and analyze the dynamic

characteristics of an assembly in motion under various load conditions. You can also export

load conditions at any motion state to Stress Analysis in Autodesk Inventor Simulation to see

how parts respond from a structural point of view to dynamic loads at any point in the range

of motion of the assembly

The dynamic simulation environment works only with Autodesk Inventor

assembly (.iam) files.

With the dynamic simulation, you can:

Have the software automatically convert all mate and insert constraints into

standard joints.

Access a large library of motion joints.

Define external forces and moments.

Create motion simulations based on position, velocity, acceleration, and

torque as functions of time in joints, in addition to external loads.

Visualize 3D motion using traces.

Export full output graphing and charts to Microsoft

Transfer dynamic and static joints and inertial forces to Autodesk Inventor

Simulation Stress Analysis or ANSYS Workbench.

Excel
