Generate Reports
After you run an analysis on a part or assembly, you can generate a report that provides a
record of the analysis environment and results.
This chapter tells you how to generate and interpret a report for an analysis, and how to save
and distribute the report.

Run Reports

After you run a simulation on a part or assembly, you can save the details of
that analysis for future reference. Use the Report command to save all the
analysis conditions and results in HTML format for easy viewing and storage.
Generate a report
1 Set up and run an analysis for your part.
2 Orient the view in the graphics region the way you want to see it in the
report.
3 On the ribbon, click Stress Analysis tab
a report for the current analysis.
4 Specify the report parameters in the dialog box. You control the report
name, filename, file location, image size, properties reported, and so on.
The report generates a variety of image orientations based on the view
orientation you established.
5 The report is then generated, presented in an internet browser, and saved
for your viewing and distribution.
5
Report panel Report to create
