6 At the bottom of the window, click the assembly tab. Your component
is updated.
7 Some portions of the simulation may now be out of date with reference
to the change. You must update these in order to have current analysis
data. If an update is necessary, right-click the Contacts node, and click
Update.
8 Repeat step 7 for each area that requires it. Then click Simulate to update
the results.
After you update the simulation, the load glyphs relocate if the feature that
they were associated with moved as a result of the geometry change. The
direction of the load does not change, even if the feature associated with the
load changes orientation.

Change Solution Conditions

After you run an analysis on your model, you can change the conditions under
which the results were obtained. Rerun the analysis to see effects of the
changes. You can edit the loads and constraints you defined, add new loads
and constraints, or delete loads and constraints. To change your simulation
conditions, enter the stress analysis environment if you are not already in it.
Delete a load or constraint
In the browser, right-click a load or constraint, and then select Delete from
the menu.
Add a load or constraint
On the Stress Analysis tab, select the command and follow the same
procedure you used to create your initial loads and constraints.
Edit a load or constraint
1 In the browser, right-click a load or constraint, and then select Edit from
the menu.
The same dialog box you used to create the load or constraint displays.
The values on the dialog box are the current values for that load or
constraint.
