Command
Probe
Display Probe La-
bels
Displacement Scale
Mesh View
Animate Displace-
ment
Use the Displacement Scale pull-down list to adjust the deformed shape
exaggeration. Select Actualto see the deformation to scale. Since the
deformations are often small, the various automatic options exaggerate the
scale so that the shape of the deformation is more pronounced.
Use the Display commands to set the shaded style to contour, smooth, or no
shading. The legend shows while contours are off.
The values of all of the display options for each results set are saved for that
results set.
Used to
Activates the Probe command. You place probes as
needed in areas of interest to display the stress values
for that point.
Toggles the visibility of probe labels.
Displays a preset list of displacement exaggeration
scales. Choose a scale that suits your need.
Displays the element mesh used in the solution in
conjunction with the result contours. Also displays
the mesh over the undeformed model.
Animates the displacement for the current result
type, displacement scale, and the progressive results
of the stress.
Set Results Display Options | 29
