Optional Parts - KitchenAid KEBS208DBL9 Parts List

30" built−in electric double oven thermal convection self−clean
Hide thumbs


Advertisement

For Models:KEBS208DBL9, KEBS208DWH9, KEBS208DBS9, KEBS208DSS9
Illus.
Part
No.
No.
DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
8185514

OPTIONAL PARTS

(Black)
(White)
Illus.
Part
No.
No.
DESCRIPTION
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242829 Wire (12 Ga.
150 c Red)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242826 Wire (14 Ga.
150 c White)
242827 Wire (14 Ga.
150 c Yellow)
242832 Wire (14 Ga.
200 c Yellow)
7
(Black Stainless) (Stainless Steel)
Illus.
Part
No.
No.
WIRING HARNESS PARTS
4451926 Harness, Wire
4449809 Screw
4455620 Harness, Wire
4450953 Conduit, Double
4450800 Screw
4448664 Clamp
4449809 Screw
112432 Nut
4452222 Spacer, Harness
4454835 Tie, Cable
4451761 Support, Wiring
4454842 Tie, Cable
313438 Clip, Harness
Miscellaneous
814381 Pin Hinge Kit
4448950 Screw, Install (4)
DESCRIPTION
(Latch)
(Main)
