- Page 1 MXD45 INSTALLATION/OWNER’S MANUAL AM/FM/CD Marine Receiver MARINE...
-
Page 2: Installation
MXD45 INSTALLATION Preparation Please read entire manual before installation. Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. -
Page 3: Wiring Diagram
Using an incorrect fuse could damage the radio. The MXD45 uses one 5 amp AGC fuse (Battery) located in-line. * CAUTION - Do not attach any speaker leads to ground as severe damage will occur. -
Page 4: Operation
MXD45 OPERATION Control Locations Release Power Volume Up/Down Audio Play/Pause Bass Boost/Mono/Stereo Tune/Track Up/Down Band Eject Mute Auto Store/Preset Scan Display Scan Local/Distance Preset 6 Preset 5 Preset 4 Preset 3/CD Intro Preset 2/CD Random Preset 1/CD Repeat... -
Page 5: General Operation
Press MUTE to silence the audio. “MUTE” will appear in the display. Press MUTE again to cancel. Press DISP to display the clock. The radio frequency (tuner mode) or CD track/elapsed time (CD player mode) show by default. Press DISP to display the clock, then release. Press and hold DISP for 2 seconds, the clock will begin to flash. - Page 6 MXD45 OPERATION General Operation Reset Audio Bass Treble Balance Fader Press and hold for more than 2 seconds to RESET the unit upon initial installation. The RESET button is located behind the faceplate. Refer to page 2 for details. Press AUD to select between Volume (default), Bass, Treble, Balance &...
-
Page 7: Tuner Operation
MXD45 OPERATION Tuner Operation Seek Tuning Press TUNE << or >> momentarily to seek the next strong station. Manual Tuning Press TUNE << or >> for more than 2 seconds, then release. “MANU” will momentarily appear in the display. Press TUNE <<... -
Page 8: Cd Player Operation
Press RDM to play all tracks in random order. Press RDM again to cancel. Random mode is retained in memory when selecting between tuner, CD player and auxiliary input modes and when the unit is turned on/off. Some CD-Rs and CD-RWs may be incompatible with this... -
Page 9: Limited One Year Warranty
This warranty gives you specific legal rights. You may also have other rights which vary from state to state. Dual Electronics Corp. warrants this product to the original purchaser to be free from defects in material and workmanship for a period of one year from the date of the original purchase. -
Page 10: Troubleshooting
MXD45 OPERATION Troubleshooting Problem Unit will not turn on Yellow wire not connected or incorrect voltage (no power) Red wire not connected or incorrect voltage Black wire not connected Fuse blown Unit has power Speaker wires not connected (but no sound) -
Page 11: Specifications
Tuning range: Usable sensitivity: Frequency response: General Total power output: Power output: Operating voltage: Speaker output impedance: Line output voltage: Dimensions: Design and specifications subject to change without notice. MXD45 OPERATION Specifications >92dB 10Hz-20kHz >65dB 1 Bit 87.5MHz-107.9MHz 8.5dBf 10dBf 40dB... - Page 12 ©2005 Dual Electronics Corp. NSA1005-V01...
