- Page 1 MXDM70 INSTALLATION/OWNERS MANUAL AM/FM/CD/MP3/WMA Marine Weather Receiver MARINE...
-
Page 2: Installation
MXDM70 Preparation Please read entire manual before installation. Before You Start • Disconnect negative battery terminal. (consult a qualified technician for instructions) • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. -
Page 3: Wiring Diagram
MWR30 Wired Remote (sold seperately) FUSE When replacing the fuse, make sure new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The MXDM70 uses one 10 amp ATM fuse located beside the wiring connector. - Page 4 The MXDM70 allows playback of your favorite MP3 and WMA files recorded on CD-R and CD-RW discs. Its powerful on-board DSP processor decodes the compressed audio while maintaining near-CD sound quality. An internal SRAM buffer provides ESP (Electronic Skip Protection) to virtually eliminate skipping and allows alphanumeric or direct track...
-
Page 5: General Operation
MXDM70 OPERATION General Operation Faceplate Removal Press RELEASE and pull away from the left side to remove. To re-install, insert right side of faceplate first then push left side to secure. Semi-permanent Remove trim ring and install supplied #1 x 7/32” Phillips Faceplate Installation head screw through left side of mounting frame into faceplate. - Page 6 MXDM70 General Operation 12/24-hour Clock Programmable Display Priority Programmable Clock Priority Reset Confirmation Beep Mute OPERATION The clock will display 12-hour AM/PM time in USA frequen- cy spacing mode (PM 10 : 00). In European frequency spac- ing mode, the clock will display 24-hour time (22:00).
- Page 7 MXDM70 OPERATION General Operation Audio Press AUDIO to select between Volume (default), Bass, Treble, Balance & Fader. Bass Press AUDIO until BAS appears Rotate encoder left/right to adjust ( -6 minimum / +6 maximum) Treble Press AUDIO until TRE appears...
-
Page 8: Tuner Operation
MXDM70 Tuner Operation Seek Tuning Manual Tuning Scan Tuning Local/Distance Band Frequency Spacing Storing and Recalling Station Presets Automatically Store Stations Preset Scan OPERATION Press TUNE or TUNE next strong station. Press TUNE or TUNE then release. "MANUAL" will momentarily appear in the display. - Page 9 Refer to the table below. Weatherband Stations - Direct Tuning Table Button Preset 1 Preset 2 Preset 3 Preset 4 Preset 5 Preset 6 BAND MXDM70 OPERATION or TUNE WB Frequency 162.400 MHz 162.425 MHz 162.450 MHz 162.475 MHz 162.500 MHz 162.525 MHz 162.550 MHz...
-
Page 10: Cd Player Operation
MXDM70 CD Player Operation Insert CD Eject CD Track Select Fast Forward and Reverse Pause Intro Repeat Random CD-R/CD-RW Compatibility OPERATION With the label facing up, insert a standard size CD into the CD slot. The CD will automatically begin playback. - Page 11 WMA Icon Folder Icon Displaying Information Character Support MXDM70 When an MP3/WMA encoded disc is first inserted, “READING” will appear in the display. Depending on the number of files and folders, this may take several seconds. icon will illuminate anytime a valid MP3 encoded disc is inserted and flash in MP3 search/navigate modes.
- Page 12 MXDM70 CD Player Operation - MP3/WMA Files Refer to the following button function table when selecting, searching or navigating MP3/WMA files and folders: MP3/WMA Button Function Table Button SEARCH ENTER Preset 1 Preset 2 Preset 3 Preset 4 Preset 5...
- Page 13 (Up one level) AUDIO to access the previous folder level (up one level). *Only available on MP3/WMA discs recorded with more than one folder. MXDM70 OPERATION " will flash in the display. Use icon will illuminate. " will illuminate. Turn the rotary encoder "...
- Page 14 MXDM70 CD Player Operation - MP3/WMA Files *Folder Access File Repeat File Repeat (Current Folder Only) Disc Random Folder Random Disc Intro Folder Intro OPERATION Press F to select the previous folder. Press F to select the next folder. *Folder access is only available on MP3/WMA discs recorded with more than one folder.
- Page 15 CD Player Operation - MP3/WMA Files Media Compatibility Playback Order Compatible Recording Formats MXDM70 The following types of discs/files are compatible: • CD-ROM (ISO), CD-R, CD-RW • CD-DA • MP3 data • WMA data The following types of discs/files are not compatible: •...
- Page 16 MXDM70 CD Player Operation - MP3/WMA Files Additional MP3/WMA Information Sampling Frequency Rates Transfer Bit rates MP3 Tag Display Recommended Settings OPERATION An internal buffer provides ESP (Electronic Skip Protection) to virtually eliminate skipping. When playing a disc recorded with regular audio files (CD-DA or .WAV) and MP3/WMA files, the unit will play the...
-
Page 17: Limited One Year Warranty
This warranty gives you specific legal rights. You may also have other rights which vary from state to state. Dual Electronics Corp. warrants this product to the original purchaser to be free from defects in material and workmanship for a period of oneyear from the date of the original purchase. -
Page 18: Specifications
MXDM70 OPERATION CD Player Signal-to-noise: Frequency response: Channel separation @ 1kHz: D/A converter: FM Tuner Tuning range: Usable sensitivity: 50dB quieting sensitivity: Stereo separation @ 1kHz: Frequency response: AM Tuner Tuning range: Usable sensitivity: Frequency response: General Total power output:... -
Page 19: Troubleshooting
The WMA file is DRM protected on display Unit will not accept CD mechanism position out of alignment a disc CD transit screws still in place MXDM70 WARRANTY Cause Check connections for proper voltage (11~16VDC) Check connection to ground Replace fuse... - Page 20 ©2005 Dual Electronics Corp. All rights reserved. Windows Media and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and or other countries. NSA1205-V01...
