ACT ACT1000 - INSTALLATION DIAGRAMS Installation

Typical ACT1000 Configuration

Card or Proximity
Reader
Sense
Clock
Data
+5v
0v
Red
Green
BATCH: 96XX-1
PRODUCT: ACT 1000 REV1.1
SERIAL NUMBER: 00XXXX
0 1 2 3 4 5 6 7 8 9
Volt Free
Tamper Contacts
Important!
Always Place Varistor
Across Lock Terminals
U nit 8 T a lla ght B us ines s C entre, W hites tow n, T a lla ght, Dublin 24, Irela nd.
T elephone: 353 1 462 2585. T elefa x : 353 1 462 2587. E -m a il: s a les @ a cces s control.ie W eb: w w w .a cces s control.ie
ACT1000 Installation Diagrams
(standalone)
A
B
0V
TX
RX
Door Contact
Push Button
Door Contact
Inter Lock
0V
OP2
OP3
Buzzer
+12V
12V+
0V
DC-
N/C
C
N/O
OMRON
5A 250VAC
5A 30VDC
Card or Proximity
Reader (Exit)
Wire both readers in parallel but leave
the SENSE line on the Exit reader unconnected.
Door
Release
Button
Power
Supply
Unit
0V
INTERLOCK
(PB2)
PUSH
BUTTON
DOOR
CONTACT
The ACT20 connects in parallel
between the reader and the controller.
An extra line (ORANGE) is used to
bring +12VDC power to the ACT20.
The shields should be joined.
Card or Proximity

Wiring for Entry/Exit Readers

Reader (Entry)
1 2 3
4 5 6
7 8 9
0
The above diagram is valid only
for clock-and-data type readers.

Wiring for Clock and Data / Wiegand Reader

For Wiegand readers .
Wire both readers in parallel but connect D0
line of the exit reader into the SENSE line on
the controller,leave the SENSE line on the
Exit reader unconnected.
ACT20 Pin Pad W iring Diagram
Connect to
12Vdc
Cable: 8 Core Screened,
0V
Max 30m
BUZZER
OP3
OP2
SENSE
BATCH: 98XX-1
UNUSED
PRODUCT: ACT20 REV2.1
SERIAL NUMBER: 012345
0 1 2 3 4 5 6 7 8 9
Controller
Controller
Sense
Clock
Data
+5V
0V
Red LED
Grn LED
+12V
Controller
Sense
Clock
Data
+5v
0v
Red Led
Grn Led
White Sense
Green Clock / Data1
Blue Data / Data 0
Red +5v
Black 0v
Brown Red Led
Yellow Grn Led
Orange (Buzzer Ctrl)
Cable ACT20
White Buzzer
Green OP2
Blue OP3
Red
Black 0V
Brown Door Contact
Yellow Push Button
Orange +12V
