To capture from a controllable device, you first need to specify the frames
you want to capture by marking those frames and creating a batch list.
You also need to indicate a file to save the marked sequences to as well as
provide a name for your reel or video source. This is especially useful if
your batch list contains marked sequences from a number of different
tapes or sources. When you perform the capture, Video Capture will
prompt you when it is time to insert the next reel.
To change the attributes of a file:
Click the Save button on the Standard toolbar or File: Save As
1.
[
Specify the name and destination for the file.
2.
You can also append subject information to the file using the Subject
and Description entry boxes and assign a thumbnail image to the file
by clicking the Select button. If you plan on using the file in Video
Editor, click the Save to library option to automatically place it in the
Production Library for easy retrieval.
Click the Options button. The Video Save Options dialog box opens
3.
with four tabs: Video Capture, General, Advanced, and
Compression.
Select either Mark in-Mark out selection or All frames in the Video
4.
Capture tab. Mark in-Mark out selection saves only the frames
occurring between a marked in and marked out section of the file,
while All frames saves all the frames in the file.
Specify the desired video attributes in the General, Advanced, and
5.
Compression tabs.
Click OK. The Video Save Options dialog box closes and you return to
6.
the Save Video File dialog box.
Click OK. The dialog box closes and Video Capture saves the file
7.
accordingly.
MEDIASTUDIO PRO USER GUIDE
to open the Save As dialog box.
]
+
CTRL S
