Using the Toolbar

You use the toolbar to access the most commonly used commands. To use the
toolbar, simply click a button to perform that command.
The following table lists each toolbar button, its associated command, and a
brief description of the action that results.
Toolbar Buttons
Button
|
130 Chapter 7 Getting Familiar with Autodesk MapGuide Author
Command Description
New Creates a new map, starting with a map of the world.
Open Opens an existing map file on a local or network drive.
Save Saves the current map.
Properties Displays the Map Window Properties dialog box, where
you can specify the name, location, and coordinate sys-
tem of a map file, set up reports, specify locations that
can be zoomed to by name, customize the popup
menu, and assign a password to the map.
Print Prints the current map view.
Copy Copies the current map view to the Clipboard as an
Enhanced Windows Metafile (EMF). Programs that can-
not display Windows metafiles (WMF) will not be able
to use the files from the Clipboard. If you use the Copy
button while the Design tab of the Map Explorer is
active, the currently selected layers or layer groups are
copied to the Clipboard.
Select Selects features in the map.
Pan Moves the map around in the map window to display
areas that are outside of the current view.
