Autodesk 15606-011408-9330 - MAPGUIDE R6.3 SITE LIC-UPG R6 User Manual page 106

-2.0
233001.5
901999.5
Note that the formats <x rotation factor> and <y rotation factor> must
always have a value of 0.0.
The ESRI world file extension depends on the raster image file format as listed
in the following table:
Raster Image Format
TGA
CALS
PNG
BMP
JPEG
TIFF
MapInfo Tab File
MapInfo uses a TAB file (.tab) to georeference a raster image. It contains
control points to map pixel coordinates in a raster image to world or map
coordinates. To work in Autodesk MapGuide Author, you need to specify the
control points so that linear scaling is possible.
The raster image formats supported by the MapInfo tab file are: TGA, CALS,
PNG, BMP, JPEG, and TIFF. The following is an example of a tab file:
Example
!table
!version 300
!charsest WindowsLatin1
Definition Table:
File "dublinca.tif"
Type "RASTER"
|
106 Chapter 5 Working with Data in Autodesk MapGuide
World File Extension
.taw
.clw
.pgw
.bpw
.jgw
.tfw
