Camera Sequence - Axis CAMERA STATION 1.1 User Manual

Camera Sequence

Camera Sequences
Add Camera button
Remove Camera
button
Add Sequence button
Remove Sequence
Sequence text
Time between camera
switches
AXIS Camera Station User's Manual
A camera sequence is a pre-defined "camera tour" i.e. a configuration that
automatically switches through all of the cameras included in the tour. The
switching interval can be set at up to 240 seconds for each camera. Once a
camera sequence has been added, the operator simply selects it from the main
window, from the View menu. A new window will pop up and display the
cameras, described in Camera Sequence, on page 13.
To add a camera to the camera sequence, click the Add Camera button and
select a camera. See page 52.
To remove a camera from the sequence, click this button and select the camera
to remove.
To add a new sequence, press the button and enter a name for it. See page 52.
To remove a sequence, press the button and select the sequence to delete.
This could be e.g. descriptive text about the camera sequence. This text is
displayed immediately after the sequence's name, in the pop-up window
showing the sequence. See page 52.
The value set here determines the number of seconds the view from each
camera is displayed.
AXIS Camera Station Administration
51
