AXIS Camera Station Administration
Example 3: Configure an alarm received from an input/output from FTP
46
An FTP alarm is an alarm from a camera or video server that uploads images to
an FTP directory. This file must be sent to c:/TempACS/ftpdir/alarmin/ and the
file must be named so that it contains the name of the I/O:
Example: If the I/O is named FrontDoor, the file from the camera should be
named e.g. FrontDoor.jpg or FrontDoor00045.jpg so that it is properly recognized
by AXIS Camera Station.
4. Check Enable External Alarm
14. Click Select Camera and select which
cameras should start recording when this
alarm is triggered. The camera must be set
to record on I/O under Recordings.
15. Click OK to save and exit.
3. Select the new alarm from the list
1. Click Add Alarm
2. Name the alarm
AXIS Camera Station User's Manual
5. Select FTP
