Axis CAMERA STATION 1.1 User Manual page 13

Camera Sequence
AXIS Camera Station User's Manual
Red= connection normal, I/O is active, recording in progress if I/O is set to Start/Stop recording.
Green= connection normal, I/O is in normal state: no recording in progress.
Yellow = no communication with I/O.
Click to open the Camera sequence window. A camera sequence is a pre-
defined "camera tour" i.e. a configuration that automatically switches through
all of the cameras included in the tour. Select the camera sequence to view
from the drop-down list.
The pre-configured switching interval can be overridden by clicking the "next"
button, or by changing the switching interval in the drop-down list.
See Camera Sequence, on page 51 for configuration.
Camera sequence switches every 15 seconds
AXIS Camera Station User Interface
Click for
detailed
camera view
13
