Axis CAMERA STATION 1.1 User Manual page 42

AXIS Camera Station Administration
Close Text
Text for Alarm ON
Text for Alarm OFF
I/O Rules
I/O only valid if I/O...
Select camera (button)
Add Alarm (button)
Delete Alarm (button)
42
The text that appears on the push button that closes the I/O.
The text that appears in the event log when port is not in its the normal state,
i.e. when activated.
The text that appears in the event log when the port is in its normal state.
On Alarm configuration in the Administration pages and the subsequent layout in AXIS Camera
The activation of an I/O can be dependent on another I/O. Check to enable and
specify the other I/O and the state it should be in to activate the first I/O.
Opens the dialog for selecting the cameras that will start recording on the
incoming alarm. For a camera to appear in this dialog, it must be registered
under the Cameras tab, see Cameras, on page 19 for instructions. Note that it is
possible to record on any camera in the system and not just on the camera with
the I/O that triggers the alarm.
Click to add a new alarm. Provide the new alarm with a name and click OK. The
new alarm is now available in the drop-down list in I/O definition (see I/O
Definition, on page 40) and can be configured.
Click to delete the alarm currently being displayed. Note that this will delete
the alarm immediately - no confirmation will be requested.
Station - I/O Status
AXIS Camera Station User's Manual
On or Off displayed
