Axis CAMERA STATION 1.1 User Manual page 38

AXIS Camera Station Administration
Enable Web server
Enable File Control
Check (watermark)
Allow clients to update
configuration
Show only one image
on playback
Sound on alarm
Enable proxy server
Proxy server
User/Password
38
Enables the AXIS Camera Station Web service and makes it possible to view live
images and recorded events from an Intranet or the Internet. The installation of
the web interface will start when OK is clicked if this option is enabled. For
information on setting up the web service, see AXIS Camera Station Web, on
page 63.
Selecting this option makes the server create a checksum for all recorded
events. If recorded images are tampered with, i.e. images are changed or
deleted, a warning is given when the recorded event is played back.
Note that once this option is enabled, it will only be possible to play those
images that have been watermarked, i.e. images that are not watermarked
cannot be played.
Enable this if client users should be allowed to modify the current
configuration from AXIS Camera Station Client. See AXIS Camera Station Client,
on page 57 for more information.
This setting allows you to view recordings as one large image in the playback
window. If No is selected, the playback window will show the current frame in
the center of the window with the four preceding frames above it and the next
four frames below it.
Specify the path to and name of the sound file (WAV) to play on alarms. Or
click the search button to go Program Files | Axis Communications | AXIS
Camera Station | Sound to select a new sound file for your alarms.
Check this option if you want to enable the use of a proxy server. If you have
cameras outside your local network and a proxy server is used for external
network access, you must enable this setting.
Enter the IP address or name of the proxy server, and port if applicable, e.g.
http://193.168.0.1:3128. Note that you cannot use an address to a script.
Enter the user and password as defined for your proxy server.
AXIS Camera Station User's Manual
