Cisco NPE-G2 - Network Processing Engine G2 Installation And Configuration Information page 14

Removing the Network Processing Engine
Figure 7-4
3
1
Power switch
2
Power receptacle
3 Captive screw
4 M5 grounding receptacles
5
M5 grounding lug
Using a 3/16-inch flat-blade screwdriver, loosen the screw below the +V lead receptacle and pull the lead
Step 4
from the connector. Repeat this step for the –V lead only. See
Network Processing Engine and Network Services Engine Installation and Configuration
7-14
Chapter 7
Removing the Strain-Relief Cover from a Cisco uBR7246VXR Router DC-Input Power
Supply
1
4
5
NPE-G1 and NPE-G2 Installation and Configuration Information
2
8
9
7
6
6
–V lead
7
+V lead
8 Strain-relief cover
9 M4 nuts and studs
Figure 7-5.
OL-4448-12
