KENMORE 580.74229400 Repair Parts List Manual

Hide thumbs

Advertisement

REPAIR
PARTS
LIST
Model No.
580.74229400
To Call
Toll Free
For Parts:
1-800-366-PART
(1-800-366-7278)
For Service:
1-800-4-MY-HOME
(1-800-469-4663)
Sears, Reobuck and Co., Hoffman Estates, IL 60179 U.S.A.
ROOM AIR CONDITIONER
The model number of your Air Conditioner can be found
on the right side of the cabinet.
All repair parts listed are available for immediate
purchase or special order when you visit your nearest
Sears Service Center, or the Service Department at most
Sears stores. To order parts by phone, call the toll free
parts number listed to the left.
When requesting service or ordering parts, always
provide the following information:
Product Type
Model Number
®
Part Number
Part Description

Advertisement

Table of Contents

   Summary of Contents for KENMORE 580.74229400

  • Page 1 ROOM AIR CONDITIONER REPAIR PARTS LIST Model No. 580.74229400 The model number of your Air Conditioner can be found on the right side of the cabinet. All repair parts listed are available for immediate To Call purchase or special order when you visit your nearest...
  • Page 2 REPAIR PARTS Room Air Conditioner To order Parts call Toll Free Model No. 580.74229400 1-800-4-MY-HOME ® (1-800-469-4663) CAUTION: Use the Kenmore part number on all orders, not the illustration number. CABINET & FRONT GRILLE ASSEMBLY 02/04 - 2 -...
  • Page 3 580.74229400 CAUTION: Use the Kenmore part number on all orders, not the illustration number. CABINET & FRONT GRILLE ASSEMBLY ILLUSTRATION PART NUMBER DESCRIPTION NUMBER FRONT GRILLE 1 - A 3530A10240A INLET GRILLE 2 - A 3530A10241A AIR FILTER ASSEMBLY 3 - A...
  • Page 4 580.74229400 CAUTION: Use the Kenmore part number on all orders, not the illustration number. CONTROL BOX ASSEMBLY 11-B 10-B 12-B 13-B 02/04 - 4 -...
  • Page 5 580.74229400 CAUTION: Use the Kenmore part number on all orders, not the illustration number. CONTROL BOX ASSEMBLY PART NUMBER DESCRIPTION ILLUSTRATION NUMBER CONTROL BOX 1 - B 4994A20045A PANEL, CONTROL 2 - B 3720A10112A COVER, CONTROL BOX 3 - B...
  • Page 6 580.74229400 CAUTION: Use the Kenmore part number on all orders, not the illustration number. AIR HANDLING & CYCLE PARTS 11-C 14-C 19-C 12-C 13-C 17-C 18-C 16-C 10-C 15-C 02/04 - 6 -...
  • Page 7 580.74229400 CAUTION: Use the Kenmore part number on all orders, not the illustration number. AIR HANDLING & CYCLE PARTS ILLUSTRATION PART NUMBER DESCRIPTION NUMBER 1 - C 3041A10050B BASE PAN WELD ASSEMBLY 2 - C 5238A10022A AIR GUIDE LOWER 3 - C...
  • Page 8 580.74229400 CAUTION: Use the Kenmore part number on all orders, not the illustration number. COMPRESSOR PARTS 10-D 12-D 11-D 02/04 - 8 -...
  • Page 9 580.74229400 CAUTION: Use the Kenmore part number on all orders, not the illustration number. COMPRESSOR PARTS ILLUSTRATION PART NUMBER DESCRIPTION NUMBER 1 - D 5014A20003A ISOLATOR, COMP 2 - D 2520UMBK1MA COMPRESSOR 3 - D 4H01811C BRACKET, WASHER 4 - D...
  • Page 10 580.74229400 CAUTION: Use the Kenmore part number on all orders, not the illustration number. INSTALLATION KIT ASSEMBLY 02/04 - 10 -...
  • Page 11 580.74229400 CAUTION: Use the Kenmore part number on all orders, not the illustration number. INSTALLATION KIT ASSEMBLY ILLUSTRATION PART NUMBER DESCRIPTION NUMBER 1 - E 4H01785B L BRACKET 2 - E 4959AR3402J CURTAIN ASSEMBLY 3 - E 4959AR3402K CURTAIN ASSEMBLY...
  • Page 12 Get it fixed, at your home or ours! Your Home For repair – in your home – of all major brand appliances, lawn and garden equipment, or heating and cooling systems, no matter who made it, no matter who sold it! For the replacement parts, accessories and owner's manuals that you need to do-it-yourself.
