- Page 1 Quick Start Guide GV-IP Camera GV-GBLF4802 GV-GDRF4800 GV-GEBF4802 Before attempting to connect or operate this product, TVTFC-QG-A please read these instructions carefully and save this manual for future use.
- Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
- Page 3 Warning and Caution If the product does not work properly, please contact your dealer or the nearest ⚫ service center. Never attempt to disassemble the camera yourself. (We shall not be responsible for any problems caused by unauthorized repair or maintenance.) Do not allow water or liquid intrusion into the camera.
- Page 4 Contents 1. Overview ......................1 1.1 GV-GBLF4802 Overview ..................1 1.2 GV-GDRF4800 Overview ..................2 1.3 GV-GEBF4802 Overview ..................4 2. Installation ......................5 2.1 Connecting the Network Cable ................5 2.2 GV-GBLF4802 Installation ..................6 2.3 GV-GDRF4800 Installation ..................8 2.4 GV-GEBF4802 Installation ..................
- Page 5 1. Overview 1.1 GV-GBLF4802 Overview Fixed Ring Power Connector Mounting Base Reset Ethernet Connector microSD Card Slot Audio Input Microphone Note: It is recommended to install the water-proof connector for outdoor installation. Press and hold the reset button for more than 10 seconds to restore to the factory default...
- Page 6 1.2 GV-GDRF4800 Overview Ethernet Connector Microphone Audio Input microSD Card Slot Power Connector Reset Note: It is recommended to install the water-proof connector for outdoor installation. Press and hold the reset button for more than 10 seconds to restore to the factory default setting.
- Page 8 1.3 GV-GEBF4802 Overview Ethernet Connector Set Screw Audio Input Microphone Power Connector microSD Card Slot Mounting Base Reset Note: It is recommended to install the water-proof connector for outdoor installation. Press and hold the reset button for more than 10 seconds to restore to the factory default setting.
- Page 9 2. Installation • Ensure the wall or ceiling is strong enough to support three times the weight of the camera. • Install the camera in a dry environment. Reattach the lower dome within 4 hours of removing it. • Avoid direct contact with the dome during installation. •...
- Page 10 2.2 GV-GBLF4802 Installation Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install and use the camera in a dry environment. IMPORTANT: You must wear anti-static gloves or discharge static electricity before removing the lower dome (bubble).
- Page 11 Secure the mounting base with the camera to the wall with screws as shown below. Bracket adjustment. Before adjustment, preview the image of the camera on a monitor and then loosen the fixed ring to adjust the viewing angle of the camera. Tighten the fixed ring after the adjustment.
- Page 12 2.3 GV-GDRF4800 Installation Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install the camera in a dry environment. You'd better install back the cover of the camera less than 4 hours after removing it. Do not remove the protection film until finishing the installation.
- Page 13 Route and connect these cables. Secure the camera to the ceiling or wall with the screws provided.
- Page 14 Three-axis adjustment. Before adjustment, preview the image of the camera on a monitor and then adjust the camera according to the figure below to get an optimum angle. Install the lower dome back to the camera and fasten it with screws. Then put the trim ring onto the lower dome and then rotate it clockwise until it is locked.
- Page 15 2.4 GV-GEBF4802 Installation Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install the camera in a dry environment. You'd better install back the cover of the camera less than 4 hours after removing it. IMPORTANT: You must wear anti-static gloves or discharge static electricity before removing the lower dome (bubble).
- Page 16 Drill the screw holes and the cable hole on the ceiling according to the drill template. Then route and connect the cables. Secure the mounting base to the ceiling or wall with the screws provided.
- Page 17 Install the camera unit and enclosure to the mounting base. Adjust the camera unit to obtain an optimum viewing angle. Finally, fasten the camera with the set screw.
- Page 18 3. Accessing the Network Camera 3.1 Looking Up the Dynamic IP Address By default, when the camera is connected to a LAN with the DHCP server, it is automatically assigned with a dynamic IP address. Follow the steps below to look up its IP address.
- Page 19 4. For first-time users, you are requested to create a password. 5. Type a new password and click OK. 6. Click its IP address on the Utility window again and select Web Page to access its Web interface. 7. Type the set password on the login page and click Login. Note: To change the password using GV-IP Device Utility, click on the camera’s IP address, and select Configure >...
- Page 20 3.2 Configuring the IP Address If the camera is connected to a LAN without a DHCP server, the default IP address will be 192.168.0.10. Follow the steps below to modify the IP address to avoid IP conflict with other GV-IP devices on the same LAN. 1.
- Page 21 4. The Web Interface Once you log in to the Web interface, you will see the live view as shown below. The following table is the instructions of the icons on the live view interface. Icon Description Icon Description AZ control (only available for the Original size model with motorized zoom lens) Fit correct scale...
- Page 22 SD card recording indicator Zoom out Note: The features described in the above table vary among camera models and versions. Some features may not be available in your camera. GV-GBLF4802, GV-GDRF4800, and GV-GEBF4802 only support the following two Event configurations: Line Crossing...
- Page 23 5. Upgrading System Firmware GeoVision periodically releases updated firmware on the company website. To load the new firmware into the camera, follow the instructions below. 1. On the Web interface, click Config > Maintenance > Upgrade. 2. Click Choose File to locate the firmware file saved at your local computer.
- Page 24 6. Restoring to Factory Default If for any reason the camera is not responding correctly, you can restore the camera back to its factory default settings using the Web interface or the Load Default Button. On the Camera 1. Find the Load Default button on the camera (see the Reset button in 1. Overview). 2.
