GV-GBL12811
GV-GBLF2802
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Quick Start Guide
GV-IP Camera
TVTBL-QG-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-GBL12811 and is the answer not in the manual?

Questions and answers

Summary of Contents for GeoVision GV-GBL12811

  • Page 1 Quick Start Guide GV-IP Camera GV-GBL12811 GV-GBLF2802 Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. TVTBL-QG-A...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 Warning and Caution ⚫ If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not be responsible for any problems caused by unauthorized repair or maintenance.) ⚫...
  • Page 4: Table Of Contents

    Contents 1. Overview ......................1 1.1 GV-GBLF2802 Overview ................1 1.2 GV-GBL12811 Overview ................3 2. Installation ......................5 2.1 GV-GBLF2802 Installation ................5 2.2 GV-GBL12811 Installation ................7 3. Accessing the Network Camera ................ 9 3.1 Looking Up the Dynamic IP Address ............9 3.2 Configuring the IP Address ................
  • Page 5: Overview

    1. Overview 1.1 GV-GBLF2802 Overview Fixed Ring Power Connector Mounting Base Reset Ethernet Connector Micro SD Card Slot Audio Input...
  • Page 6 Note: It is recommended to install the water-proof connector for outdoor installation. Press and hold the reset button for more than 10 seconds to restore to the factory default setting. Connecting Network Cable Note: If the RJ 45 connector of the network cable has a jacket and cannot be threaded through the kit, remove the jacket.
  • Page 7: Gv-Gbl12811 Overview

    1.2 GV-GBL12811 Overview Ethernet Connector Microphone Audio Input (MIC) Reset* Audio Output (HP) DC IN & CVBS Interface CVBS Video Output Zoom - Alarm Input / Output Zoom + Power Connector * Micro SD Card Slot Note: It is recommended to install the water-proof connector for outdoor installation.
  • Page 8 Alarm Connection Alarm Input: Join the grounding ends of the sensor and the camera and then connect the signal cable of the sensor to the alarm input port of the camera. Alarm Output: Loosen the screws in the alarm output port. Then insert the signal wires of the alarm output devices into the port of COM and OPEN separately.
  • Page 9: Installation

    2. Installation 2.1 GV-GBLF2802 Installation Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install and use the camera in the dry environment. Install a micro SD card as needed. Remove the memory slot cover from the camera by loosening the two screws and then install a micro SD card.
  • Page 10 Secure the mounting base with camera to the wall with screws as shown below. Bracket adjustment. Before adjustment, preview the image of the camera on a monitor and then loosen the fixed ring to adjust the viewing angle of the camera. Tighten the fixed ring after the adjustment.
  • Page 11: Gv-Gbl12811 Installation

    2.2 GV-GBL12811 Installation Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install the camera in a dry environment. You'd better install back the cover of the camera less than 4 hours after removing it.
  • Page 12 Open the cover of the camera as shown in the following figure and then insert a micro SD card. After that, press the T or W button to obtain an optimum image. Before adjustment, view the image of the camera on a monitor. Install the cover back to the camera and secure it firmly with the screws.
  • Page 13: Accessing The Network Camera

    3. Accessing the Network Camera 3.1 Looking Up the Dynamic IP Address By default, when the camera is connected to a LAN with the DHCP server, it is automatically assigned with a dynamic IP address. Follow the steps below to look up its IP address.
  • Page 14 4. For first-time users, you are requested to create a password. 5. Type a new password and click OK. 6. Click its IP address on the Utility window again and select Web Page to access its Web interface. 7. Type the set password on the login page and click Login. Note: The Administrator’s default username is admin and cannot be modified.
  • Page 15: Configuring The Ip Address

    3.2 Configuring the IP Address If the camera is connected to a LAN without a DHCP server, the default IP address will be 192.168.0.10. Follow the steps below to modify the IP address to avoid IP conflict with other GV-IP devices on the same LAN. 1.
  • Page 16: The Web Interface

    4. The Web Interface Once you log in the Web interface, you will see the live view as shown below. Icon Description Icon Description Original size Sensor alarm indicator Fit correct scale Motion alarm indicator Auto (fill the window) Color abnormal indicator Full screen Abnormal clarity indicator Measure Tool...
  • Page 17 Icon Description Icon Description Snapshot Region Entrance indicator Start/stop local recording Region Exiting indicator Zoom in Face detection indicator Zoom out Target Counting by Line indicator AZ control (only available for the Target Counting by Area indicator model with motorized zoom lens) Face capture (when face event is Object detection indicator (object selected)
  • Page 18: Upgrading System Firmware

    5. Upgrading System Firmware GeoVision periodically releases updated firmware on the company website. To load the new firmware into the camera, follow the instructions below. 1. On the Web interface, click Config > Maintenance > Upgrade. 2. Click Choose File to locate the firmware file saved at your local computer.
  • Page 19: Restoring To Factory Default

    6. Restoring to Factory Default If for any reason the camera is not responding correctly, you can restore the camera back to its factory default settings using the Web interface or the Load Default Button. On the Camera 1. Find the Load Default button on the camera (see No. 11, 1. Overview in the Quick Start Guide).
