Quick Start Guide
GV-GEBF4911
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
TVTG-QG-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-GEBF4911 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-GEBF4911

Summary of Contents for GeoVision GV-GEBF4911

  • Page 1 Quick Start Guide GV-GEBF4911 Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. TVTG-QG-A...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 Warning and Caution ⚫ If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not be responsible for any problems caused by unauthorized repair or maintenance.) ⚫...

  • Page 4: Table Of Contents

    Contents 1. Overview ......................1 2. Installation ......................3 3. Accessing the Network Camera ................ 7 3.1 Looking Up the Dynamic IP Address ............7 3.2 Configuring the IP Address ................9 4. The Web Interface ..................... 10 5. Upgrading System Firmware ................12 6.

  • Page 5: Overview

    1. Overview Ethernet connector (PoE) Microphone Audio input Micro SD card slot Audio output Default button Warm LED Alarm input/output IR LED Power port (DC 12V) Active Deterrence LED Speaker...
  • Page 6 Note: It is recommended to install the water-proof connector for outdoor installation. To load default settings, press and hold the default button for 10 seconds. Connecting Alarm Input/Output Alarm Input Alarm Output Max. load: DC 30V, 1A...

  • Page 7: Installation

    2. Installation Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install and use the camera in a dry environment. Loosen the set screw and then move the camera unit to expose the cover of the SD card slot.
  • Page 8 3. Drill the screw holes and the cable hole on the ceiling according to the drill template. Then route and connect the cables. (a). Loosen the nut from the main element. (b). Run the network cable (without RJ 45 connector) through the both elements. Then crimp the cable with RJ 45 connector.
  • Page 9 4. Secure the mounting base to the ceiling or wall with the screws provided. 5. Install the dome and enclosure to the mounting base. 6. Adjust the camera to obtain an optimum angle. Before adjustment, preview the image of the camera on a monitor.
  • Page 10 7. Tighten the set screw after you finish adjusting the viewing angle of the camera.

  • Page 11: Accessing The Network Camera

    3. Accessing the Network Camera Looking Up the Dynamic IP Address By default, when the camera is connected to a LAN with the DHCP server, it is automatically assigned with a dynamic IP address. Follow the steps below to look up its IP address.
  • Page 12 5. Type a new password and click OK. 6. Click on its IP address again and select Webpage to open its Web interface. 7. Type the set password on the login page and click Login. IMPORTANT: 1. To change the password using GV-IP Device Utility, click on the camera’s IP address, and select Configure >...

  • Page 13: Configuring The Ip Address

    Configuring the IP Address If the camera is connected to a LAN without the DHCP server, the default IP address will be 192.168.0.10. Follow the steps below to modify the IP address to avoid IP conflict with other GV-IP devices on the same LAN. 1.

  • Page 14: The Web Interface

    4. The Web Interface After logging in, the following window will be shown. The following table is the instructions of the icons on the live view interface. Icon Description Icon Description Original size SD card recording indicator Fit correct scale Sensor alarm indicator Adapt Motion alarm indicator...
  • Page 15 Icon Description Icon Description Target Counting by Area AZ control indicator Object detection indicator PTZ control (object Abandoned/Missing) Face Detection Heat map indicator Crowd density detection Rule information display indicator Video metadata extraction indicator For detailed information, see the user’s manual.

  • Page 16: Upgrading System Firmware

    5. Upgrading System Firmware GeoVision periodically releases updated firmware on the company website. To load the new firmware into the camera, follow the instructions below. 1. On the Web interface, click Config > Maintenance > Upgrade. 2. Click the Choose File button to locate the firmware file saved at your local computer.

  • Page 17: Restoring To Factory Default

    6. Restoring to Factory Default If for any reason the camera is not responding correctly, you can restore the camera back to its factory default settings using the Web interface or the Load Default Button. On the Camera 1. Find the Load Default button on the camera (see No. 9, 1. Overview in the Quick Start Guide).

  • Page 18: Connecting To Gv-Cloud Vms

    7. Connecting to GV-Cloud VMS To connect GV-GEBF4911 to GV-Cloud VMS, follow the steps below. Note: Region Intrusion and Motion Detection will be automatically enabled when the camera is successfully connected to GV-Cloud VMS. The following events are supported on GV-Cloud VMS: Motion Detection, Region Intrusion, I/O events.
  • Page 19 Click Send. The message “Host has been added” will appear. Keep the created Host Code and Password for connecting to GV-Cloud on the camera. On GV-GEBF4911 Web Interface Go to Config → Service → GV-Cloud. Enable the Connection and fill in the Host Code and Password.

  • Page 20: Connecting To Gv-Center V2

    Create at least one subscriber before starting Center V2 services. See 1.4.1 Creating a Subscriber in the GV-CMS Series User’s Manual. On GV-GEBF4911 Web Interface Go to Config → Service → GV-Center V2. Enable the Connection and enter the IP Address of GV-Center V2, User Name, and Password set up in GV-Center V2 for the camera as a subscriber.

  • Page 21: Optional Installation

    9. Optional Installation Junction Box GV-Mount506 Packing List GV-Mount506 Plastic case (7 x 42 mm) x 4 Short screw (4 x 10 mm) x 4 Long screw (6.5 x 38 mm) x 4 Waterproof ring x 4 Drill Template Paster Dimension...
  • Page 22 GV-Mount506 Installation Before installation, make sure that the wall is strong enough to withstand 3 times the weight of the junction box and the camera. Drill the screw holes on the wall according to the drill template. Open the mounting base and the upper cover of GV-Mount506. Secure the mounting base of GV-Mount506 to the wall.
  • Page 23 Loosen the set screw and detach the mounting base of the camera. Secure the camera’s mounting base to the upper cover of GV-Mount506 first, and install the dome and enclosure to the camera’s mounting base.
  • Page 24 Route the cables through the cable hole (take side conduit cabling for example) and connect the cables. Then reinstall the upper cover to GV-Mount506. Adjust the view angle of the camera.

  • Page 25: Wall Mount Bracket Gv-Mount211-4

    Wall Mount Bracket GV-Mount211-4 Packing List GV-Mount211-4 Short screw (4 x10 mm) x 4 Long screw (4 x 25 mm) x 4 Colloidal particle x 4 Hex Key Drill Template Paster Dimension...
  • Page 26 GV-Mount211-4 Installation Before installation, make sure that the wall is strong enough to withstand 3 times the weight of the brackets and the camera. The followings take straight cable outlet from the wall for example. Unscrew and remove the mounting base of GV-Mount211-4. Loosen the set screw and detach the mounting base of the camera.
  • Page 27 Drill the screw holes on the wall according to the drill template. Secure the mounting base of GV-Mount211-4 to the wall. Route the cables through the cable hole and connect the cables.
  • Page 28 Fix GV-Mount211-4 to its mounting base on the wall.

  • Page 29: Wall Mount Bracket Gv-Mount211-6

    Wall Mount Bracket GV-Mount211-6 Packing List GV-Mount211-6 Screw (3 x6 mm) x 2 Screw (6 x 12 mm) x 4 Screw (4 x 25 mm) x 3 Waterproof ring x 4 Plastic case (6 x 29) x 3 Drill Template Paster Note: GV-Mount211-6 must be used with GV-Mount506.
  • Page 30 GV-Mount211-6 Installation Open the mounting base and the upper cover of GV-Mount506. Loosen the set screw and detach the mounting base of the camera. Secure the camera’s mounting base to the upper cover of GV-Mount506 first, and install the dome and enclosure to the camera’s mounting base.
  • Page 31 Assemble GV-Mount211-6, and fix the mounting base of GV-Mount506 to GV-Mount211-6. Route the cables through the cable hole of GV-Mount211-6 and connect the cables.
  • Page 32 Secure the camera mounted with the upper cover of GV-Mount506 to GV-Mount211-6. Secure GV-Mount211-6 to the wall.
