Quick Start Guide
GV-GPTZ4810
Before attempting to connect or operate this product,
GPTZ-QG-A
please read these instructions carefully and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-GPTZ4810 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-GPTZ4810

Summary of Contents for GeoVision GV-GPTZ4810

  • Page 1 Quick Start Guide GV-GPTZ4810 Before attempting to connect or operate this product, GPTZ-QG-A please read these instructions carefully and save this manual for future use.
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Warning And Caution

    Warning and Caution ⚫ If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not be responsible for any problems caused by unauthorized repair or maintenance.) ⚫...

  • Page 4: Table Of Contents

    Contents 1. Overview ......................1 1.1 Camera Overview ..................1 1.2 Cable Connection ..................2 2. Installation ......................4 3. Accessing the Network Camera ................ 6 3.1 Looking Up the Dynamic IP Address ............6 3.2 Configuring the IP Address ................8 4.

  • Page 5: Overview

    1. Overview 1.1 Camera Overview Ethernet connector (PoE) Microphone MIC-Audio input (3.5 mm) Ground HP-Audio output (3.5 mm) Memory card slot Alarm input / output Reset DC 12V power jack Note: 1. The product must be grounded to reduce the risk of electric shock. 2.

  • Page 6: Cable Connection

    1.2 Cable Connection Connecting Network Cable Note: If the RJ-45 connector of the network cable has a jacket and cannot be threaded through the kit, remove the jacket. If the jacket cannot be removed, cut off the connector and install an RJ 45 connector without the jacket.
  • Page 7 Connecting Alarm Input / Output The max. load of alarm output: DC 30V, 1A.

  • Page 8: Installation

    2. Installation Make sure that the wall is strong enough to the weight of the camera and the camera is powered off during installation. Note: The recommended installation height is 3 ~ 5 m for smart tracking. Memory Card Installation Loosen the two screws of the cover and then remove the cover.
  • Page 9 Ceiling Mounting Use the four screws provided to install the Align the three screw holes of the adapter with adapter to the ceiling. the screws of the mounting base. Adjust the camera position and then tighten the Put the three screws into the screw holes. After that, turn the camera clockwise to secure it.

  • Page 10: Accessing The Network Camera

    3. Accessing the Network Camera 3.1 Looking Up the Dynamic IP Address By default, when the camera is connected to a LAN with a DHCP server, it is automatically allocated a dynamic IP address. Follow the steps below to look up its IP address, and then use that address to access its Web interface.
  • Page 11 4. For first-time users, you are requested to create a password. 5. Type a new password and click OK. 6. Click on its IP address on the Utility window again and select Web Page to access its Web interface. 7. Type the set password on the login page and click Login. Note: To change the password using GV-IP Device Utility, click on the camera’s IP address, and select Configure >...

  • Page 12: Configuring The Ip Address

    3.2 Configuring the IP Address If the camera is connected to a LAN without a DHCP server, the default IP address will be 192.168.0.10. To avoid IP conflict with other GV-IP devices on the same LAN, configure an IP address as described below. 1.

  • Page 13: The Web Interface

    4. The Web Interface Once you log in the Web interface, you will see the live view as shown below. Note: The main stream over 1080P, two-way audio, local recording, and the preview mode switch (real-time / balanced / fluent mode) are only supported in IE mode in Microsoft Edge.
  • Page 14 Icon Description Icon Description PTZ control Move the cursor to view the live image in all direction after you click this button. Additionally, hold and drag the left mouse button to zoom in the live image. Click to show PTZ control panel. In the live view interface, you can view the image from every direction by controlling PTZ panel.

  • Page 15: Upgrading System Firmware

    5. Upgrading System Firmware GeoVision periodically releases updated firmware on the company website. To load the new firmware into the camera, follow the instructions below. Using Camera’s Web Interface 1. On the Web interface, click Config > Maintenance > Upgrade.
  • Page 16 2. Click the Firmware Upgrade tab, click the Browse button to locate the firmware file saved at your local computer. 3. Click the Upgrade button to start upgrading the firmware. 4. After upgrading, the camera will restart automatically.

  • Page 17: Restoring To Factory Default

    6. Restoring to Factory Default If for any reason the camera is not responding correctly, you can restore the camera back to its factory default settings using the Web interface or the Reset Button. On the Camera 1. Find the Reset button on the camera (see 1.1 Overview in the Quick Start Guide). 2.
