Summary of Contents for GeoVision GV-GDR2081
- Page 1 Quick Start Guide GV-IP Camera GV-GBL12811 GV-GBLF2802 GV-GDR2081 Before attempting to connect or operate this product, TVTBLDR-QG-A please read these instructions carefully and save this manual for future use.
- Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
-
Page 3: Warning And Caution
Warning and Caution If the product does not work properly, please contact your dealer or the nearest ⚫ service center. Never attempt to disassemble the camera yourself. (We shall not be responsible for any problems caused by unauthorized repair or maintenance.) Keep away from liquid while in use. -
Page 4: Table Of Contents
Contents 1. Overview ......................1 1.1 GV-GBLF2802 Overview ..................1 1.2 GV-GBL12811 Overview ..................2 1.3 GV-GDR2801 Overview ..................4 2. Installation ......................5 2.1 Connecting the Network Cable ................5 2.2 GV-GBLF2802 Installation ..................6 2.3 GV-GBL12811 Installation ..................8 2.4 GV-GDR2801 Installation .................. -
Page 5: Overview
1. Overview 1.1 GV-GBLF2802 Overview Fixed Ring Power Connector Mounting Base Reset Ethernet Connector Micro SD Card Slot Audio Input Note: It is recommended to install the water-proof connector for outdoor installation. Press and hold the reset button for more than 10 seconds to restore to the factory default setting. -
Page 6: Gv-Gbl12811 Overview
1.2 GV-GBL12811 Overview Ethernet Connector Microphone Audio Input (MIC) Reset Audio Output (HP) DC IN & CVBS Interface CVBS Video Output Zoom - Alarm Input / Output Zoom + Power Connector Micro SD Card Slot Note: It is recommended to install the water-proof connector for outdoor installation. Press and hold the reset button for more than 10 seconds to restore to the factory default setting. - Page 7 Alarm Connection Alarm Input: Join the grounding ends of the sensor and the camera and then connect the signal cable of the sensor to the alarm input port of the camera. Alarm Output: Loosen the screws in the alarm output port. Then insert the signal wires of the alarm output devices into the port of COM and OPEN separately.
-
Page 8: Gv-Gdr2801 Overview
1.3 GV-GDR2801 Overview Ethernet Connector Power Connector Audio Input (MIC) Micro SD Card Slot Reset Note: It is recommended to install the water-proof connector for outdoor installation. Press and hold the reset button for more than 10 seconds to restore to the factory default setting. -
Page 9: Installation
2. Installation Ensure the wall or ceiling is strong enough to support three times the weight of • the camera. Install the camera in a dry environment. Reattach the lower dome within 4 • hours of removing it. Avoid direct contact with the dome during installation. •... -
Page 10: Gv-Gblf2802 Installation
2.2 GV-GBLF2802 Installation Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install and use the camera in the dry environment. Install a microSD card as needed. Remove the memory slot cover from the camera by loosening the two screws and then install a microSD card. - Page 11 Secure the mounting base with camera to the wall with screws as shown below. Bracket adjustment. Before adjustment, preview the image of the camera on a monitor and then loosen the fixed ring to adjust the viewing angle of the camera. Tighten the fixed ring after the adjustment.
-
Page 12: Gv-Gbl12811 Installation
2.3 GV-GBL12811 Installation Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install the camera in a dry environment. You'd better install back the cover of the camera less than 4 hours after removing it. Drill the screw holes and the cable hole (if you want to route through the ceiling) on the wall or ceiling according to the drill template. - Page 13 Open the cover of the camera as shown in the following figure and then insert a microSD card. After that, press the T or W button to obtain an optimum image. Before adjustment, view the image of the camera on a monitor. Install the cover back to the camera and secure it firmly with the screws.
-
Page 14: Gv-Gdr2801 Installation
2.4 GV-GDR2801 Installation Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install the camera in a dry environment. You'd better install back the cover of the camera less than 4 hours after removing it. IMPORTANT: You must wear anti-static gloves or discharge static electricity before removing the lower dome (bubble). - Page 15 Route and connect the cables. Secure the camera to the ceiling or wall with the screws provided.
- Page 16 Three-axis adjustment. Before adjustment, preview the image of the camera on a monitor and then adjust the camera according to the figure below to get an optimum angle. Install the lower dome back to the camera and fasten it with screws. Finally, remove the protection film softly.
-
Page 17: Accessing The Network Camera
3. Accessing the Network Camera 3.1 Looking Up the Dynamic IP Address By default, when the camera is connected to a LAN with the DHCP server, it is automatically assigned with a dynamic IP address. Follow the steps below to look up its IP address. - Page 18 4. For first-time users, you are requested to create a password. 5. Type a new password and click OK. 6. Click its IP address on the Utility window again and select Web Page to access its Web interface. 7. Type the set password on the login page and click Login. Note: The Administrator’s default username is admin and cannot be modified.
-
Page 19: Configuring The Ip Address
3.2 Configuring the IP Address If the camera is connected to a LAN without a DHCP server, the default IP address will be 192.168.0.10. Follow the steps below to modify the IP address to avoid IP conflict with other GV-IP devices on the same LAN. 1. -
Page 20: The Web Interface
4. The Web Interface Once you log in the Web interface, you will see the live view as shown below. Icon Description Icon Description Original size Sensor alarm indicator Fit correct scale Motion alarm indicator Auto (fill the window) Color abnormal indicator Full screen Abnormal clarity indicator Measure Tool... - Page 21 Icon Description Icon Description Snapshot Region Entrance indicator Start/stop local recording Region Exiting indicator Zoom in Face detection indicator Zoom out Target Counting by Line indicator AZ control (only available for the Target Counting by Area indicator model with motorized zoom lens) Face capture (when face event is Object detection indicator (object selected)
-
Page 22: Upgrading System Firmware
5. Upgrading System Firmware GeoVision periodically releases updated firmware on the company website. To load the new firmware into the camera, follow the instructions below. 1. On the Web interface, click Config > Maintenance > Upgrade. 2. Click Choose File to locate the firmware file saved at your local computer. -
Page 23: Restoring To Factory Default
6. Restoring to Factory Default If for any reason the camera is not responding correctly, you can restore the camera back to its factory default settings using the Web interface or the Load Default Button. On the Camera 1. Find the Load Default button on the camera (see No. 11, 1. Overview in the Quick Start Guide).
