- Page 1 Quick Start Guide GV-IP Cloud Cameras GV-GBL4900 / GBL4911 GV-GDR4900 GV-GEB4900 GV-GEBF4911 GV-GVD4910 Before attempting to connect or operate this product, TVTG-QG-C please read these instructions carefully and save this manual for future use.
- Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
- Page 3 Warning and Caution ⚫ If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not be responsible for any problems caused by unauthorized repair or maintenance.) ⚫...
-
Page 4: Table Of Contents
Contents 1. Overview ......................1 1.1 GV-GBL4900 ......................1 1.2 GV-GBL4911 ......................4 GV-GDR4900 ......................7 GV-GEB4900......................10 GV-GEBF4911 ...................... 12 GV-GVD4910 ....................... 14 2. Installation ...................... 19 GV-GBL4900 ......................19 2.2 GV-GBL4911 ......................21 2.3 GV-GDR4900 ......................24 2.4 GV-GEB4900 ......................27 2.5 GV-GEBF4911 ...................... -
Page 5: Overview
1. Overview GV-GBL4900... - Page 6 Adjusting ring Power connector (DC 12V) Mounting base Micro SD card slot Ethernet connector (PoE) Default button Microphone MIC-Audio input connector IR LED x 2 HP-Audio output connector Alarm input/output Note: It is recommended to install the waterproof connector for outdoor installation. This series can be powered by DC 12V / PoE power supply.
- Page 7 Connecting Alarm Input / Output Connecting Network Cable Loosen the nut from the main element. Run the network cable (without RJ 45 connector) through the both elements. Then crimp the cable with RJ 45 connector. Connect the cable to the Ethernet connector. Then tighten the nut and the main cover.
-
Page 8: Gv-Gbl4911
GV-GBL4911... - Page 9 Ethernet connector (PoE) Default button MIC-Audio input connector DC IN & CVBS Interface HP-Audio output connector Zoom - Zoom + CVBS Video Output Micro SD card slot Alarm input/output IR LED x 4 (the 2 LED lights in the middle will be on at long Power connector (DC 12V) shots) Microphone...
- Page 10 Run the network cable (without RJ 45 connector) through the both elements. Then crimp the cable with RJ 45 connector. Connect the cable to the Ethernet connector. Then tighten the nut and the main cover.
-
Page 11: Gv-Gdr4900
GV-GDR4900... - Page 12 Ethernet connector (PoE) Microphone MIC-Audio input connector Micro SD card slot HP-Audio output connector Default button IR LED x 2 Alarm input/output Power connector (DC 12V) Note: It is recommended to install the waterproof connector for outdoor installation. This series can be powered by DC 12V / PoE power supply. If the PoE switch is used to power the camera, DC 12V power supply is not required.
- Page 13 Connecting Alarm Input / Output Alarm Input Alarm Output Contact parameters of Relay: Max. Voltage: DC 30V Max. Current: 1A...
-
Page 14: Gv-Geb4900
GV-GEB4900... - Page 15 Ethernet connector (PoE) Fixed Screw MIC-Audio input connector Microphone HP-Audio output connector Micro SD card slot Default button Power connector (DC 12V) IR LED Mounting Base Note: It is recommended to install the waterproof connector for outdoor installation. This series can be powered by DC 12V / PoE power supply. If the PoE switch is used to power the camera, DC 12V power supply is not required.
-
Page 16: Gv-Gebf4911
GV-GEBF4911 Ethernet connector (PoE) Microphone Audio input Micro SD card slot Audio output Default button Warm LED Alarm input/output IR LED Power port (DC 12V) Active Deterrence LED Speaker... - Page 17 Note: It is recommended to install the water-proof connector for outdoor installation. To load default settings, press and hold the default button for 10 seconds. Connecting Alarm Input/Output Alarm Input Alarm Output Max. load: DC 30V, 1A...
-
Page 18: Gv-Gvd4910
GV-GVD4910... - Page 19 Ethernet connector (PoE) Zoom + MIC-Audio input Micro SD card slot HP-Audio output Default button DC IN & CVBS Interface CVBS Video Output Microphone Alarm input/output IR LED x 3 (the third LED light will Power port (DC 12V) be on at long shots) Zoom - Note: It is recommended to install the water-proof connector for outdoor installation.
- Page 20 Connecting Alarm Input / Output Contact parameters of Relay: Contact Load: resistive: 1A 125V AC / 24V DC Max. Voltage: 30V DC / 125V AC Max. Current: 1A Min. Current & Voltage: 10mA, 5V DC...
-
Page 21: Installation
2. Installation GV-GBL4900 Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install the camera under a dry environment. Drill the screw holes and the cable hole on the wall according to the drill template. - Page 22 Bracket adjustment. Before adjustment, preview the image of the camera on a monitor and then loosen the adjusting ring to adjust the viewing angle of the camera. Tighten the adjusting ring after the adjustment. Open the cover of the camera and then insert a micro-SD card. Install the cover back to the camera and secure it firmly with the screws.
-
Page 23: Gv-Gbl4911
GV-GBL4911 Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install the camera in a dry environment. You'd better install back the cover of the camera less than 4 hours after removing it. Drill the screw holes and the cable hole (if you want to route through the ceiling) on the wall or ceiling according to the drill template. - Page 24 Bracket adjustment. Before adjustment, preview the image of the camera on a monitor (see the figure of step 5) and then loosen the lock screws to adjust the view angle of the camera. After that, tighten the lock screws. Open the cover of the camera as shown in the following figure and then insert a micro-SD card.
- Page 25 Install the cover back to the camera and secure it firmly with the screws. Note: Please install the cover back in the same way you disassemble it, in case the sealing performance is affected.
-
Page 26: Gv-Gdr4900
GV-GDR4900 Note: Make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. You should reinstall the lower dome in less than 4 hours of its removal. Do not remove the protection film until finishing the installation. Use two fingers to remove the trim ring from the rim with marks. - Page 27 Route and connect these cables. (A) Loosen the nut from the main element. (B) Run the network cable (without RJ 45 connector) through the both elements. Then crimp the cable with RJ 45 connector. (C) Connect the cable to the Ethernet connector. Then tighten the nut and the main cover.
- Page 28 Secure the camera to the ceiling or wall with the screws provided. Three-axis adjustment. Before adjustment, preview the image of the camera on a monitor and then adjust the camera according to the figure below to get an optimum angle. Replace the lower dome to the camera and make sure the light sensor can be seen from the outside.
-
Page 29: Gv-Geb4900
GV-GEB4900 Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install and use the camera in a dry environment. Loosen the fixed screw to dissemble the camera. Unscrew the cover of the dome and then insert a micro SD card. After that, install back the cover and make sure the cover is installed firmly. - Page 30 Drill the screw holes and the cable hole on the ceiling according to the drill template. Then route and connect the cables. (a) Loosen the nut from the main element. (b) Run the network cable (without RJ 45 connector) through the both elements. Then crimp the cable with RJ 45 connector.
- Page 31 Secure the mounting base to the ceiling or wall with the screws provided. Install the dome and enclosure to the mounting base. Then adjust the dome to obtain an optimum viewing angle.
- Page 32 Finally, fasten the camera with the fixed screw.
-
Page 33: Gv-Gebf4911
GV-GEBF4911 Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install and use the camera in a dry environment. Loosen the set screw and then move the camera unit to expose the cover of the SD card slot. - Page 34 3. Drill the screw holes and the cable hole on the ceiling according to the drill template. Then route and connect the cables. (a). Loosen the nut from the main element. (b). Run the network cable (without RJ 45 connector) through the both elements. Then crimp the cable with RJ 45 connector.
- Page 35 4. Secure the mounting base to the ceiling or wall with the screws provide d. 5. Install the dome and enclosure to the mounting base. 6. Adjust the camera to obtain an optimum angle. Before adjustment, preview the image of the camera on a monitor.
- Page 36 7. Tighten the set screw after you finish adjusting the viewing angle of the camera .
-
Page 37: Gv-Gvd4910
GV-GVD4910 Note: Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install the camera in a dry environment. You'd better install back the lower dome less than 4 hours after removing it. Do not remove the protection film until finishing the installation. - Page 38 Route and connect these cables. Loosen the nut from the main element. Run the network cable (without RJ-45 connector) through the both elements. Then crimp the cable with RJ-45 connector. Connect the cable to the Ethernet connector. Then tighten the nut and the main cover.
- Page 39 Secure the camera to the ceiling or wall with the screws provided. Three-axis adjustment. Before adjustment, preview the image of the camera on a monitor and then adjust the camera according to the figure below to get an optimum angle. Press the T or W button to obtain an optimum image.
-
Page 40: Accessing The Network Camera
This function is only applicable on GV-IP Device Utility V8.9.8 or later for GV-GDR4900 / GEB4900 / GEBF4911, and V9.0.1 or later for GV-GBL4900 / GBL4911 / GVD4910. 1. Make sure the PC used to configure the IP address is under the same LAN as the camera. - Page 41 5. Type a new password and click OK. 6. Click on its IP address again and select Webpage to open its Web interface. 7. Type the set password on the login page and click Login. IMPORTANT: 1. To change the password using GV-IP Device Utility, click on the camera’s IP address, and select Configure >...
-
Page 42: Configuring The Ip Address
Configuring the IP Address If the camera is connected to a LAN without the DHCP server, the default IP address will be 192.168.0.10. Follow the steps below to modify the IP address to avoid IP conflict with other GV-IP devices on the same LAN. 1. -
Page 43: The Web Interface
4. The Web Interface After logging in, the following window will be shown. The following table is the instructions of the icons on the live view interface. Icon Description Icon Description Original size Sensor alarm indicator Fit correct scale Motion alarm indicator Adapt Color abnormal indicator Full screen... - Page 44 Object detection indicator (object Zoom out Abandoned/Missing) AZ control (only for Heat map indicator GV-GEBF4911) Loitering detection indicator (not PTZ control available for GV-GEBF4911) Illegal parking detection indicator Face Detection (not available for GV-GEBF4911) Video metadata extraction Rule information display indicator For detailed information, see the user’s manual.
-
Page 45: Upgrading System Firmware
5. Upgrading System Firmware GeoVision periodically releases updated firmware on the company website. To load the new firmware into the camera, follow the instructions below. 1. On the Web interface, click Config > Maintenance > Upgrade. 2. Click the Choose File / Browse button to locate the firmware file saved at your local computer. -
Page 46: Restoring To Factory Default
6. Restoring to Factory Default If for any reason the camera is not responding correctly, you can restore the camera back to its factory default settings using the Web interface or the Load Default Button. On the Camera 1. Find the Load Default button on the camera (see 1. Overview in the Quick Start Guide). 2. - Page 47 For GV-GBL4900 / GBL4911 / GDR4900 / GEB4900 / GVD4910 On the Web interface, click Config >Maintenance > Backup and Restore. Click Restore Factory Settings and then verify the password to restore all system settings to the default factory settings.
-
Page 48: Connecting To Gv-Cloud Vms
When the camera is rebooted after connecting to GV-Cloud The following events are supported on GV-Cloud VMS: A. GV-GBL4900 / GBL4911 / GDR4900 / GEB4900 / GVD4910: Motion Detection, Region Entrance, Region Exiting, Region Intrusion, Line Crossing, Video Exception (Scene Change / Video Blur Detection), I/O events. - Page 49 Select Host in the left menu, and click in the upper right corner. This dialog box appears. Type Display Name, Password (to be the host’s GV-Cloud login password), and select Time Zone for the host. The rest information is optional. Click Send.
- Page 50 Go to Config → System → Storage to set up the service quota from the camera’s SD card for the snapshots and recordings uploaded onto GV-Cloud VMS. For details, see 4.1.4 Storage in the user’s manual. Note: It is recommended to set the Cloud Service Quota to 90% to prioritize cloud storage over the camera’s storage.
-
Page 51: Connecting To Gv-Center V2
To connect to GV-Center V2, follow the steps below: Note: The following events are supported on GV-Center V2: GV-GBL4900 / GBL4911 / GDR4900 / GEBF4911 / GVD4910: Motion Detection, Region Intrusion, Line Crossing, Region Entrance, Region Exiting, Video Exception (Scene Change Detection), I/O events. -
Page 52: Optional Installation
9. Optional Installation Wall Mount Bracket GV-Mount211-4 Packing List GV-Mount211-4 Short screw (4 x10 mm) x 4 Long screw (4 x 25 mm) x 4 Colloidal particle x 4 Hex Key Drill Template Paster Note: GV-Mount211-4 is applicable to GV-GDR4900 / GEBF4911 / GEB4900. Dimension... - Page 53 GV-Mount211-4 Installation Before installation, make sure that the wall is strong enough to withstand 3 times the weight of the brackets and the camera. The followings take straight cable outlet from the wall for example. Unscrew and remove the mounting base of GV-Mount211-4. Loosen the set screw and detach the mounting base of the camera.
- Page 54 Drill the screw holes on the wall according to the drill template. Secure the mounting base of GV-Mount211-4 to the wall. Route the cables through the cable hole and connect the cables.
- Page 55 Fix GV-Mount211-4 to its mounting base on the wall.
-
Page 56: Wall Mount Bracket Gv-Mount211-6
Wall Mount Bracket GV-Mount211-6 Packing List GV-Mount211-6 Screw (3 x6 mm) x 2 Screw (6 x 12 mm) x 4 Screw (4 x 25 mm) x 3 Waterproof ring x 4 Plastic case (6 x 29) x 3 Drill Template Paster Note: GV-Mount211-6 must be used with GV-Mount506. - Page 57 GV-Mount211-6 Installation Open the mounting base and the upper cover of GV-Mount506. Loosen the set screw and detach the mounting base of the camera. Secure the camera’s mounting base to the upper cover of GV-Mount506 first, and install the dome and enclosure to the camera’s mounting base.
- Page 58 Assemble GV-Mount211-6, and fix the mounting base of GV-Mount506 to GV-Mount211-6. Route the cables through the cable hole of GV-Mount211-6 and connect the cables.
- Page 59 Secure the camera mounted with the upper cover of GV-Mount506 to GV-Mount211-6. Secure GV-Mount211-6 to the wall.
-
Page 60: Wall Mount Bracket Gv-Mount211-8
Wall Mount Bracket GV-Mount211-8 Packing List GV-Mount211-8 Screw (3 x 6 mm) x 2 Screw (4 x 12 mm) x 4 Screw (4 x 25 mm) x 3 Waterproof ring x 4 Plastic case (6 x 29) x 3 Drill Template Paster Note: GV-Mount211-8 must be used with GV-Mount506-1. - Page 61 Dimension GV-Mount211-8 Installation Open the mounting base and the upper cover of GV-Mount506-1. Loosen the set screw and detach the mounting base of the camera.
- Page 62 Secure the camera’s mounting base to the upper cover of GV-Mount506-1 first, and install the dome and enclosure to the camera’s mounting base. Assemble GV-Mount211-8, and fix the mounting base of GV-Mount506-1 to GV-Mount211-8.
- Page 63 Route the cables through the cable hole of GV-Mount211-8 and connect the cables. Secure the camera mounted with the upper cover of GV-Mount506-1 to GV-Mount211-8. Secure GV-Mount211-8 to the wall.
-
Page 64: Wall Mount Bracket Gv-Mount211-9
Wall Mount Bracket GV-Mount211-9 Packing List GV-Mount211-8 Screw (3 x 6 mm) x 2 Screw (4 x 12 mm) x 4 Screw (4 x 25 mm) x 3 Waterproof ring x 4 Plastic case (6 x 29) x 3 Drill Template Paster Note: GV-Mount211-9 must be used with GV-Mount509. - Page 65 Dimension GV-Mount211-9 Installation Assemble GV-Mount211-9.
- Page 66 Secure GV-Mount509 with GV-Mount211-9. Use two fingers to remove the trim ring of the camera from the rim with marks. Then loosen the screws to open the lower dome.
- Page 67 Attach the camera base to GV-Mount509. Route the cables through the cable hole of GV-Mount211-9 and connect the cables.
- Page 68 Put the trim ring back onto the lower dome and assemble the camera. Secure GV-Mount211-9 to the wall.
-
Page 69: Junction Box Gv-Mount506
Plastic case (7 x 42 mm) x 4 Short screw (4 x 10 mm) x 4 Long screw (6.5 x 38 mm) x 4 Waterproof ring x 4 Drill Template Paster Note: GV-Mount506 is applicable to GV-GBL4900 / GEBF4911. Dimension... - Page 70 GV-Mount506 Installation Before installation, make sure that the wall is strong enough to withstand 3 times the weight of the junction box and the camera. Drill the screw holes on the wall according to the drill template. Open the mounting base and the upper cover of GV-Mount506. Secure the mounting base of GV-Mount506 to the wall.
- Page 71 Loosen the set screw and detach the mounting base of the camera. Secure the camera’s mounting base to the upper cover of GV-Mount506 first, and install the dome and enclosure to the camera’s mounting base.
- Page 72 Route the cables through the cable hole (take side conduit cabling for example) and connect the cables. Then reinstall the upper cover to GV-Mount506. Adjust the view angle of the camera.
-
Page 73: Junction Box Gv-Mount506-1
Junction Box GV-Mount506-1 Packing List GV-Mount506-1 Plastic case (4 x 10 mm) x 4 Screw (4 x 25 mm) x 4 Waterproof ring x 5 Plastic case (6 x 29) x 4 Drill Template Paster Note: GV-Mount506-1 is applicable to GV-GEB4900. Dimension... - Page 74 GV-Mount506-1 Installation Before installation, make sure that the wall is strong enough to withstand 3 times the weight of the junction box and the camera. Drill the screw holes on the wall according to the drill template. Open the mounting base and the upper cover of GV-Mount506-1. Secure the mounting base of GV-Mount506-1 to the wall.
- Page 75 Loosen the set screw and detach the mounting base of the camera. Secure the camera’s mounting base to the upper cover of GV-Mount506-1 first, and install the dome and enclosure to the camera’s mounting base.
-
Page 76: Junction Box Gv-Mount507
Screw (4 x 10 mm) x 4 Screw (4 x 25 mm) x 3 Screw (3 x 6 mm) x 1 Plastic case x 3 Hex Key x 1 Waterproof ring x 5 Drill Template Paster Note: GV-Mount507 is applicable to GV-GBL4900. Dimension... - Page 77 We only introduce the installation of some cameras with junction box in this manual. Note that this is only applicable to GV-GBL4900. Open the lower cover and the upper cover of the junction box by loosening the fixed screw.
- Page 78 Fix the camera to the upper cover of the junction box. Then route the cables through the cable hole (take side conduit cabling for example) and connect the cables. Install the camera with the upper cover of the junction box to the lower cover, with a clockwise rotation and then secure the junction box by tightening the fixed screw.
- Page 79 Adjust the view angle of the camera.
-
Page 80: Junction Box Gv-Mount507-1
Junction Box GV-Mount507-1 Packing List GV-Mount507-1 Screw (4 x 10 mm) x 4 Screw (4 x 25 mm) x 4 Plastic case x 4 Waterproof ring x 4 Drill Template Paster Note: GV-Mount507-1 is applicable to GV-GBL4900. Dimension... - Page 81 GV-Mount507-1 Installation Disassemble GV-Mount507-1 first. Secure the camera onto the cover of GV-Mount507-1 using the supplied screws as indicated below.
- Page 82 Assemble the camera and the bottom of GV-Mount507-1 using the screws as indicated below. The installation is completed.
-
Page 83: Junction Box Gv-Mount509
Junction Box GV-Mount509 Packing List GV-Mount506-1 Screw (4 x 12 mm) x 5 Screw (4 x 22 mm) x 5 Screw (4 x 25 mm) x 4 Plastic case (6 x 25 mm) x 4 Drill Template Paster Note: GV-Mount509 is applicable to GV-GDR4900. Dimension... - Page 84 GV-Mount509 Installation Use two fingers to remove the trim ring of the camera from the rim with marks. Then loosen the screws to open the lower dome. Secure the camera onto GV-Mount509 using the supplied screws.
- Page 85 Assemble the camera and finish the installation.
-
Page 86: Junction Box Gv-Mount510
9.10 Junction Box GV-Mount510 Packing List GV-Mount510 Screw (4 x 16 mm) x 4 Screw (6.5 x 38 mm) x 4 Plastic case (8 x 40 mm) x 4 Screw waterproof ring x 4 PG waterproof ring x 1 Drill Template Paster Note: GV-Mount510 is applicable to GV-GVD4910. - Page 87 GV-Mount510 Installation Secure the junction box to the wall or ceiling with screws. Rotate the trim ring anticlockwise to remove it from the camera and then loosen the screws to open the lower dome. Route and connect these cables. Then fasten the camera to the junction box with screws.
-
Page 88: In-Ceiling Mounting Bracket Gv-Mount925
9.11 In-Ceiling Mounting Bracket GV-Mount925 Packing List GV-Mount925 Screw (4 x 10 mm) x 4 Drill Template Paster Note: GV-Mount925 is applicable to GV-GVD4910. - Page 89 Dimension GV-Mount925 Installation Attach the drill template to the ceiling where you want to install the dome camera. Then cut a hole according to the drill template. Note that +2mm of the circle diameter is allowed.
- Page 90 Rotate the trim ring anticlockwise to remove it. Then remove the lower dome of the camera by loosening the screws. After that, place the in-ceiling bracket on the dome camera and make sure the screw holes of the dome camera are aligned with the screw holes of the bracket marked with “A”.
- Page 91 Tighten the lock screws with the screwdriver and the locks will automatically rotate outwards to secure the dome camera to the ceiling. Then adjust the view angle of the camera. Install the lower dome back to the camera. Then put the trim ring onto the lower dome and rotate it clockwise until it is locked.
