Malibu
626/3724 625/0744 625/7259 622/9603 702/9187
706/0957 728/8784 826/8466 863/5219 470/7471
419/8035
IMPORTANT - Retain these instructions for future reference
Spare Parts
Visit: www.argos-support.co.uk
Email: Help@ClickSpares.co.uk
Call: 0370 112 1928
C R
C R
C R
C R
C R
C R
C R
Customer Support
Call: 0345 640 2020
Issue 22 - 03/11/22
Advertisement
Related Manuals for Argos Malibu 626/3724
Summary of Contents for Argos Malibu 626/3724
- Page 1 Malibu 626/3724 625/0744 625/7259 622/9603 702/9187 706/0957 728/8784 826/8466 863/5219 470/7471 419/8035 IMPORTANT - Retain these instructions for future reference Spare Parts Customer Support Visit: www.argos-support.co.uk Call: 0345 640 2020 Email: Help@ClickSpares.co.uk Call: 0370 112 1928 Issue 22 - 03/11/22...
- Page 2 Safety Important - Please read these instructions fully before starting assembly • WARNING: To prevent • Warning: This unit weighs possible overbalancing this unit approximately 38kgs. must be secured to a wall using Please lift with care. the 2 overbalance protector kits •...
- Page 3 Cabinet Panels 5 71.4 x 9.2cm 6 71.4 x 6cm 7 71.4 x 7.6cm 1 107.1 x 39.4cm 2 107.1 x 39.4cm 3 74.8 x 39.6cm 4 16 x 37.2cm 8 98.9 x 74.1cm Drawer Panels Note: the internal drawer panels are grey 35.2 x 15.6cm 70.75 x 15.6cm 35.2 x 15.6cm...
- Page 4 Fittings Use these drawings to correctly identify the fittings Bag 1 x 10 x 13 x 14 x 14 x 42 x 24 Bag 2 x 14 x 14 x 28 x 28 x 12 x 10 Tools Only used for drilling walls...
- Page 5 Fittings x 12 Tools Only used for drilling walls...
- Page 6 Fixing Bottom Mounted Runners h�ps://www.youtube.com/watch?v=Z6lGMy19h7Q Bag 1 x 10 x 13 x 14 x 36 x 14 x 42 x 24 Finished front edge Finished front edge x 12...
- Page 7 10mm Push against panel...
- Page 8 Note: Panel 6 has no holes drilled on either surface Finished front edge Finished front edge Finished front edge...
- Page 9 Panel Assembly Turn the cam clockwise until the h�ps://www.youtube.com/watch?v=33kDsSSfxjw arrow points in the same direction as shown in the diagram below IMPORTANT: USE A FLAT-HEADED SCREWDRIVER Turn the cam clockwise until the arrow points in the same direction as shown in the diagram below IMPORTANT: USE A FLAT-HEADED SCREWDRIVER...
- Page 10 Turn the cam clockwise until the arrow points in the same direction as shown in the diagram below IMPORTANT: USE A FLAT-HEADED SCREWDRIVER Warning: Support this panel until the other end is fitted in the next step Turn the cam clockwise until the arrow points in the same direction as shown in the diagram below IMPORTANT: USE A...
- Page 11 Note: Due to the manufacturing process, the 3 holes for the large locking cam can be on either surface of the divider. Finished front edge Finished front edge...
- Page 12 Finished front edge Push against panel Remember: The 3 large locking nuts can be on either surface of the divider Turn the cam clockwise until the arrow points in the same direction as shown in the diagram below IMPORTANT: USE A FLAT-HEADED SCREWDRIVER Finished front edge...
- Page 13 Turn the cam clockwise until the arrow points in the same direction as shown in the diagram below IMPORTANT: USE A FLAT-HEADED SCREWDRIVER Finished front edge Squaring up a Chest and fitting the Back Panel www.youtube.com/watch?v=FeaI6541z7o A = B Make sure measurement A and B are the same before attaching Back Panel...
- Page 14 x 24...
- Page 15 WARNING! In order to prevent overturning this product must be used with the 2 wall attachment devices provided See the next section for a guide to wall mounting and fixings Back Carefully stand the unit up and push it up against the wall. Fit the 1st screw through the bracket and up into the shallow mark-hole drilled into the...
- Page 16 A Guide to Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
- Page 17 Large Drawer Assembly Bag 2 x 14 x 14 x 28 x 28 x 12 x 10 Drawer Assembly www.youtube.com/watch?v=InNBV_uuMmo Push against panel x 10 x 10 IMPORTANT: USE A FLAT-HEADED SCREWDRIVER Turn the cam clockwise until the arrow points in the same direction as shown in the diagram below...
- Page 18 x 20 x 10 x 10...
- Page 19 x 10 Important: Make sure that the drawer assembly is square before fitting the drawer brace. Warning: Fit the front screw 1st. x 20 Fixing Bottom Mounted Runners https://www.youtube.com/watch?v=Z6lGMy19h7Q Runners must be pushed up against the drawer front...
- Page 20 Small Drawer Assembly Bag 2 x 14 x 14 x 28 x 28 x 12 x 10 Drawer Assembly www.youtube.com/watch?v=InNBV_uuMmo Note: The Right Hand Push Drawer Front has a against small marker hole panel Mark the Right Hand Drawer Front with an IMPORTANT: USE A FLAT-HEADED SCREWDRIVER Turn the cam clockwise until the...
- Page 22 Fixing Bottom Mounted Runners https://www.youtube.com/watch?v=Z6lGMy19h7Q Runners must be pushed up against the drawer front...
- Page 23 Fixing Bottom Mounted Runners https://www.youtube.com/watch?v=Z6lGMy19h7Q Fit the Drawer Front you marked with here Assembly is complete Please remove any blue protective film from panel edges and clear protective film from panel surfaces...
- Page 24 ALR3296...
