- Page 1 User’s Manual Stand Fan FS40-15F READ AND SAVE THESE INSTRUCTIONS Attention: Pictures in the IM are for reference only.
- Page 3 CAUTION Read Rules for Safe Operation and Instructions Carefully. WARNING 1. If the supply cord is damaged, it must be replaced by manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. 2. To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid.
- Page 4 PART FIGURE Front grill Fan blade Plastic nut Motor shaft Clutch knob Motor housing Case Piano switch Circlip Rear grill Thumb Timer screw (Optional) Internal Pole Spinner Extension Pole Height Adjustment Ring Chassis 7-shape Bolt Note: All the pictures in this manual are for explanation purpose only. Any discrepancy between the real object and the illustration in the drawing shall be subject to the real subject.
- Page 5 Fig.1 Fig.2 Fig.3 Fig.4 Mounting hole Thumb screw Loose e n Annular groove GRILL & FAN BLADE ASSEMBLY 1. Unscrew the spinner clockwise (or take the spinner out from the bag) and the plastic nut counterclockwise to remove both of them. Fix the rear grill to the motor then tighten the plastic nut again.
- Page 6 OPERATING INSTRUCTION 1. Speed is controlled by the piano switch. 0---Off 1---Low 2---Medium 3---High 2. Turn the knob of timer switch to position which set the time you want, the fan will stop when the time is over. The longest time set is 120 minutes. In case the timer is not use, set the timer switch to “ON”.
