Driver Set Information Value
Create a new partition on this driver set Deselect this option.
Driver Instance for the Connection from Source to Destination
Driver Set Information Value
Pre-configured driver template to import (pick one):
BCCClusterResourceSynchronization.xml
UserObjectSynchronization.xml
TIP: The User Object Synchronization driver is
needed only when creating a driver instance for
communications between clusters in different trees. In
this case, create one driver instance for resource
synchronization and one driver instance for user
object synchronization.
Driver name for this driver instance
Example: cluster1_to_cluster2 BCCCR Sync
Example: cluster1_to_cluster2 BCCUO Sync
Default: BCC Cluster Sync
SSL certificate name to use for this driver instance
Example: cluster1_to_cluster2 BCCCR Sync
Example: cluster1_to_cluster2 BCCUO Sync
Default: BCC Cluster Sync (kmo)
IP address or DNS name of the Identity Manager
node in the destination cluster for this driver instance
Example: 10.10.20.21
Example: cl2svr1.cluster2.clusters.siteB.example
Unique IP port to use for this driver instance
Example: 2002 (default for resource sync)
Example: 2001 (default for user object sync)
TIP: Both clusters must use the same port for this
connection.
Distinguished name of the source cluster
Example: cluster1.clusters.siteA.example
TIP: Browse to select the cluster.
