FRENCH COUNTRY
HARDWARE LIST
CODE
NAME
CAM LOCKS
A
CAM BOLTS
B
RAIL SCREW
C
(Φ1/4"*38mm)
SPRING WASHER
D
(Φ1/4")
FLAT WASHER
E
(Φ1/4"*16mm)
ALLEN WRENCH
F
Please do not return to the store
If you have any questions just call 1-800-468-6447 or email us at
parts@convenience-concepts.com
Item No. 6042182
FIGURE
Q'TY
3PCS
3PCS
6PCS
6PCS
6PCS
1PC
ENTRYWAY TABLE
M6042182
6042182BL
6042182W
PARTS LIST
CODE
NAME
TOP PANEL
1
BOTTOM PANEL
2
LEFT LEG
3
RIGHT LEG
4
CENTER LEG
5
FIGURE
Q'TY
1PC
1PC
1PC
1PC
1PC
